Parameter Description
26-50 Terminal X42/9 Output
Option: Function:
Set the function of terminal X42/9.
[0] No operation
*
[100] Output freq. 0-100 0-100 Hz, (0-20 mA)
[101] Reference Min-Max Minimum reference - Maximum
reference, (0-20 mA)
[102] Feedback +-200% -200% to +200% of 3-03 Maximum
Reference, (0-20 mA)
[103] Motor cur. 0-Imax 0 - Inverter Max. Current (16-37 Inv.
Max. Current), (0-20 mA)
[104] Torque 0-Tlim 0 - Torque limit (4-16 Torque Limit
Motor Mode), (0-20 mA)
[105] Torque 0-Tnom 0 - Motor rated torque, (0-20 mA)
[106] Power 0-Pnom 0 - Motor rated power, (0-20 mA)
[107] Speed 0-HighLim 0 - Speed High Limit (4-13 Motor
Speed High Limit [RPM] and 4-14 Motor
Speed High Limit [Hz]), (0-20 mA)
[108] Torque +-160%
[109] Out frq 0-Fmax
[113] Ext. Closed Loop 1 0 - 100%, (0-20 mA)
[114] Ext. Closed Loop 2 0 - 100%, (0-20 mA)
[115] Ext. Closed Loop 3 0 - 100%, (0-20 mA)
[139] Bus ctrl. 0 - 100%, (0-20 mA)
[141] Bus ctrl t.o. 0 - 100%, (0-20 mA)
26-51 Terminal X42/9 Min. Scale
Range: Function:
0.00 [0.00 - Scale the minimum output of the selected
% 200.00 %] analog signal at terminal X42/9, as a
*
percentage of the maximum signal level.
E.g. if a 0 V is desired at 25% of the
maximum output value. Then programme
25%. Scaling values up to 100% can never
be higher than the corresponding setting
in 26-52 Terminal X42/9 Max. Scale.
See principle graph for 6-51 Terminal 42 Output Min Scale.
26-52 Terminal X42/9 Max. Scale
Range: Function:
100.00 [0.00 - Scale the maximum output of the selected
% 200.00 analog signal at terminal X42/9. Set the value
*
%] to the maximum value of the voltage signal
output. Scale the output to give a voltage
lower than 10 V at full scale; or 10 V at an
output below 100% of the maximum signal
value. If 10 V is the desired output current at
a value between 0-100% of the full-scale
output, programme the percentage value in
the parameter, i.e. 50% = 10 V. If a voltage
®
VLT AQUA Drive Programming Guide
26-52 Terminal X42/9 Max. Scale
Range:
See principle graph for 6-52 Terminal 42 Output Max Scale.
26-53 Terminal X42/9 Bus Control
Range:
0.00 %
26-54 Terminal X42/9 Timeout Preset
Range:
0.00 %
26-60 Terminal X42/11 Output
Option:
[0]
[100] Output freq. 0-100 0-100 Hz, (0-20 mA)
[101] Reference Min-Max Minimum reference - Maximum
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[108] Torque +-160%
[109] Out frq 0-Fmax
[113] Ext. Closed Loop 1 0-100%, (0-20 mA)
[114] Ext. Closed Loop 2 0-100%, (0-20 mA)
[115] Ext. Closed Loop 3 0-100%, (0-20 mA)
[139] Bus ctrl.
[141] Bus ctrl t.o.
®
MG20O602 - VLT is a registered Danfoss trademark
Function:
between 0 and 10V is desired at maximum
output, calculate the percentage as follows:
i.e.
V
10
V : x 100 % = 200 %
5
5 V
Function:
[0.00 - 100.00 %] Holds the level of terminal X42/9 if
*
controlled by bus.
Function:
[0.00 - Holds the preset level of terminal X42/9.
*
100.00 %] In case of a bus timeout and a timeout
function is selected in 26-60 Terminal
X42/11 Output the output will preset to
this level.
Function:
Set the function of terminal X42/11.
No operation
*
reference, (0-20 mA)
-200% to +200% of 3-03 Maximum
Reference, (0-20 mA)
0 - Inverter Max. Current (16-37 Inv.
Max. Current), (0-20 mA)
0 - Torque limit (4-16 Torque Limit
Motor Mode), (0-20 mA)
0 - Motor rated torque, (0-20 mA)
0 - Motor rated power, (0-20 mA)
0 - Speed High Limit (4-13 Motor
Speed High Limit [RPM] and 4-14 Motor
Speed High Limit [Hz]), (0-20 mA)
0-100%, (0-20 mA)
0-100%, (0-20 mA)
