Parameter Description
18-33 Analog Out X42/7 [V]
Range: Function:
0.000 [0.000 - Read out of the value of the signal
*
30.000 ] applied to terminal X42/7 on the Analog
I/O Card (MCB 109).
The value shown reflects the selection in
26-40 Terminal X42/7 Output.
18-34 Analog Out X42/9 [V]
Range: Function:
0.000 [0.000 - Read out of the value of the signal
*
30.000 ] applied to terminal X42/9 on the Analog
I/O Card (MCB 109).
The value shown reflects the selection in
26-50 Terminal X42/9 Output.
18-35 Analog Out X42/11 [V]
Range: Function:
0.000 [0.000 - Read out of the value of the signal
*
30.000 ] applied to terminal X42/11 on the
Analog I/O Card (MCB 109).
The value shown reflects the selection in
26-60 Terminal X42/11 Output.
18-36 Analog Input X48/2 [mA]
Range: Function:
0.000 [-20.000 - 20.000 ] View the actual current measured at
*
input X48/2 (MCB 114).
18-37 Temp. Input X48/4
Range: Function:
0 [-500 - 500 ] View the actual temperature measured at
*
input X48/4 (MCB 114). The temperature unit
is based on the selection in 35-00 Term. X48/4
Temp. Unit.
18-38 Temp. Input X48/7
Range: Function:
0 [-500 - 500 ] View the actual temperature measured at
*
input X48/7 (MCB 114). The temperature unit
is based on the selection in 35-02 Term. X48/7
Temp. Unit.
18-39 Temp. Input X48/10
Range: Function:
0 [-500 - 500 ] View the actual temperature measured at
*
input X48/10 (MCB 114). The temperature
unit is based on the selection in 35-04 Term.
X48/10 Temp. Unit.
®
VLT AQUA Drive Programming Guide
3.16.3 18-6* Inputs & Outputs 2
18-60 Digital Input 2
Range:
0
®
MG20O602 - VLT is a registered Danfoss trademark
Function:
[0 - 65535 ] View the signal states from the active digital
*
inputs on the MCO 102 (Advanced Cascade
Controller): Counting from right to left the
positions in the binary are: DI7...DI1 ⇒ pos.
2 ...pos. 8.
3 3
