Troubleshooting
No. Description
61 Feedback Error
62 Output Frequency at Maximum Limit
63 Mechanical Brake Low
64 Voltage Limit
65 Control Board Over-temperature
66 Heat sink Temperature Low
67 Option Configuration has Changed
5 5
68 Safe Stop
69 Pwr. Card Temp
70 Illegal FC configuration
71 PTC 1 Safe Stop
72 Dangerous failure
73 Safe Stop Auto Restart
74 PTC Thermistor
75 Illegal Profile Sel.
76 Power Unit Setup
77 Reduced power mode
78 Tracking Error
79 Illegal PS config
80 Drive Initialized to Default Value
81 CSIV corrupt
82 CSIV parameter error
83 Illegal Option Combination
84 No Safety Option
88 Option Detection
89 Mechanical Brake Sliding
90 Feedback Monitor
91 Analog input 54 wrong settings
163 ATEX ETR cur.lim.warning
164 ATEX ETR cur.lim.alarm
165 ATEX ETR freq.lim.warning
166 ATEX ETR freq.lim.alarm
250 New spare parts
251 New Type Code
Table 5.1 Alarm/Warning Code List
(X) Dependent on parameter
1) Can not be Auto reset via 14-20 Reset Mode
A trip is the action when an alarm has appeared. The trip
will coast the motor and can be reset by pressing [Reset]
or make a reset by a digital input (parameter group 5-1*
[1]). The origin event that caused an alarm cannot damage
the frequency converter or cause dangerous conditions. A
trip lock is an action when an alarm occurs, which may
226
®
VLT AQUA Drive Programming Guide
Warning Alarm/Trip
(X) (X)
X
(X)
X
X
X
(X)
(X)
(X) (X)
X
X
(X) (X)
X
(X) (X)
X
X
damage the frequency converter or connected parts. A Trip
Lock situation can only be reset by a power cycling.
Table 5.2
®
MG20O602 - VLT is a registered Danfoss trademark
Alarm/Trip Lock
X X
X
1)
X X
X
X
X
X X
X
X
X
X
X
X
X
X
X
X
X X
LED indication
Warning
Alarm
Trip locked
Parameter
Reference
4-30 Motor Feedback
Loss Function
2-20 Release Brake
Current
5-19 Terminal 37 Digital
Input
5-19 Terminal 37 Digital
Input
14-59 Actual Number of
Inverter Units
4-34 Tracking Error
Function
17-61 Feedback Signal
Monitoring
S202
yellow
flashing red
yellow and red
