Danfoss VLT AQUA Drive FC 200 Programming Manual page 105

Parameter Description
13-52 SL Controller Action
Array [20]
Option:
[13] Select preset ref
3
3 3
[14] Select preset ref
4
[15] Select preset ref
5
[16] Select preset ref
6
[17] Select preset ref
7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC Brake
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A
low
[33] Set digital out B
low
[34] Set digital out C
low
[35] Set digital out D
low
[36] Set digital out E
low
[37] Set digital out F
low
104
®
VLT AQUA Drive Programming Guide
Function:
Selects preset reference 3.
Selects preset reference 4.
Selects preset reference 5.
Selects preset reference 6.
Selects preset reference 7. If the active
preset reference is changed, it will
merge with other preset reference
commands coming from either the
digital inputs or via a fieldbus.
Selects ramp 1
Selects ramp 2
Issues a start command to the
frequency converter.
Issues a start reverse command to the
frequency converter.
Issues a stop command to the
frequency converter.
Issues a DC stop command to the
frequency converter.
The frequency converter coasts
immediately. All stop commands
including the coast command stop the
SLC.
Freezes the output frequency of the
frequency converter.
Starts timer 0, see 13-20 SL Controller
Timer for further description.
Starts timer 1, see 13-20 SL Controller
Timer for further description.
Starts timer 2, see 13-20 SL Controller
Timer for further description.
Any output with 'digital output 1'
selected is low (off).
Any output with 'digital output 2'
selected is low (off).
Any output with 'digital output 3'
selected is low (off).
Any output with 'digital output 4'
selected is low (off).
Any output with 'digital output 5'
selected is low (off).
Any output with 'digital output 6'
selected is low (off).
MG20O602 - VLT
13-52 SL Controller Action
Array [20]
Option:
[38] Set digital out A
high
[39] Set digital out B
high
[40] Set digital out C
high
[41] Set digital out D
high
[42] Set digital out E
high
[43] Set digital out F
high
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
[80] Sleep Mode
[81] Derag
®
is a registered Danfoss trademark
Function:
Any output with 'digital output 1'
selected is high (closed).
Any output with 'digital output 2'
selected is high (closed).
Any output with 'digital output 3'
selected is high (closed).
Any output with 'digital output 4'
selected is high (closed).
Any output with 'digital output 5'
selected is high (closed).
Any output with 'digital output 6'
selected is high (closed).
Resets Counter A to zero.
Resets Counter A to zero.
Starts timer 3, see 13-20 SL Controller
Timer for further description.
Starts timer 4, see 13-20 SL Controller
Timer for further description.
Starts timer 5, see 13-20 SL Controller
Timer for further description.
Starts timer 6, see 13-20 SL Controller
Timer for further description.
Starts timer 7, see 13-20 SL Controller
Timer for further description.
Starts the Sleep Mode.
Starts Deragging (see parameter groups
29-1* to 29-3* for further information)
