13-40 Logic Rule Boolean 1
Array [6]
Option:
[27] Logic rule 1
3 3
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
100
®
VLT AQUA Drive Programming Guide
Function:
Use the result of logic rule 1 in the
logic rule.
Use the result of logic rule 2 in the
logic rule.
Use the result of logic rule 3 in the
logic rule.
Use the result of timer 0 in the logic
rule.
Use the result of timer 1 in the logic
rule.
Use the result of timer 2 in the logic
rule.
Use the value of DI18 in the logic rule
(High = TRUE).
Use the value of DI19 in the logic rule
(High = TRUE).
Use the value of DI27 in the logic rule
(High = TRUE).
Use the value of DI29 in the logic rule
(High = TRUE).
Use the value of DI32 in the logic rule
(High = TRUE).
Use the value of DI33 in the logic rule
(High = TRUE).
This logic rule is TRUE if the frequency
converter is started by any means
(either via digital input, field bus or
other).
This logic rule is TRUE if the frequency
converter is stopped or coasted by any
means (either via digital input, fieldbus
or other).
This logic rule is TRUE if the frequency
converter is tripped (but not trip-
locked) and [Reset] is pressed.
This logic rule is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
This logic rule is TRUE if the OK key on
the LCP is pressed.
This logic rule is TRUE if the Reset key
on the LCP is pressed.
This logic rule is TRUE if the Left key
on the LCP is pressed.
MG20O602 - VLT
13-40 Logic Rule Boolean 1
Array [6]
Option:
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
13-41 Logic Rule Operator 1
Array [6]
Option:
[0] DISABLED
*
[1] AND
[2] OR
[3] AND NOT
®
is a registered Danfoss trademark
Function:
This logic rule is TRUE if the Right key
on the LCP is pressed.
This logic rule is TRUE if the Up key on
the LCP is pressed.
This logic rule is TRUE if the Down key
on the LCP is pressed.
Use the result of comtor 4 in the logic
rule.
Use the result of comtor 5 in the logic
rule.
Use the result of logic rule 4 in the
logic rule.
Use the result of logic rule 5 in the
logic rule.
Use the result of timer 3 in the logic
rule.
Use the result of timer 4 in the logic
rule.
Use the result of timer 5 in the logic
rule.
Use the result of timer 6 in the logic
rule.
Use the result of timer 7 in the logic
rule.
Function:
Select the first logical operator to use on
the Boolean inputs from 13-40 Logic Rule
Boolean 1 and 13-42 Logic Rule Boolean 2.
[13-**] signifies the boolean input of
parameter group 13-**.
Ignores 13-42 Logic Rule Boolean 2,
13-43 Logic Rule Operator 2, and 13-44 Logic
Rule Boolean 3.
Evaluates the expression [13-40] AND
[13-42].
Evaluates the expression [13-40] OR [13-42].
Evaluates the expression [13-40] AND NOT
[13-42].
