Parameter Description
8-05 End-of-Timeout Function
Option:
[1] Resume set-
*
3 3
up
8-06 Reset Control Timeout
Option:
[0] Do not
*
reset
[1] Do
reset
8-07 Diagnosis Trigger
Option:
[0] Disable
*
[1] Trigger on alarms
[2] Trigger alarm/warn.
8-08 Readout Filtering
If the speed feedback value readouts on fieldbus are fluctuating,
this function is used. Select filtered if the function is required. A
power-cycle is required for changes to take effect.
Option:
[0]
*
[1]
84
Function:
frequency converter resumes its original set-
up.
Resumes the set-up active before the time-
out.
Function:
This parameter is active only when the choice [0]
Hold set-up has been selected in 8-05 End-of-
Timeout Function.
Retains the set-up specified in 8-04 Control
Timeout Function, [7] Set-up 1, [8] Set-up 2, [9] Set-
up 3 and [10] Set-up 4 following a control time-
out.
Returns the frequency converter to the original
set-up following a control word time-out. When
the value is set to [1] Do reset, the frequency
converter performs the reset and then
immediately reverts to the [0] Do not reset setting.
Function:
This parameter has no function for
BACnet.
Function:
Motor Data Std- Select [0] for normal bus
Filt. readouts.
Motor Data LP- Select [1] for filtered bus
Filter readouts of the following
parameters:
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-14 Motor Current
16-16 Torque [Nm]
16-17 Speed [RPM]
16-22 Torque [%]
16-25 Torque [Nm] High
MG20O602 - VLT
®
VLT AQUA Drive Programming Guide
3.9.2 8-1* Ctrl. Word Settings
8-10 Control Profile
Option:
[0] FC profile
*
[1] PROFIdrive profile
[5] ODVA
[7] CANopen DSP 402
8-13 Configurable Status Word STW
Option:
[0] No function
[1] Profile
*
Default
[2] Alarm 68
Only
[3] Trip excl.
Alarm 68
[10] T18 DI
status.
[11] T19 DI
status.
[12] T27 DI
status.
[13] T29 DI
status.
[14] T32 DI
status.
[15] T33 DI
status.
[16] T37 DI
status
[21] Thermal
warning
®
is a registered Danfoss trademark
Function:
Select the interpretation of the control
and status words corresponding to the
installed fieldbus. Only the selections
valid for the fieldbus installed in slot A
will be visible in the LPC display.
Function:
This parameter enables configuration of bits
12–15 in the status word.
Function corresponds to the profile default
selected in 8-10 Control Profile.
Only set in case of an Alarm 68.
Set in case of a trip, except if Alarm 68
executes the trip.
The bit indicates the status of terminal 18.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 19.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 27.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 29.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 32.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 33.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 37.
0" indicates T37 is low (safe stop)
"1" indicates T37 is high (normal)
The thermal warning turns on when the
temperature exceeds the limit in the motor,
the frequency converter, the brake resistor,
or the thermistor.
