Parameter Description
13-02 Stop Event
Option: Function:
[11] Below speed low See parameter group 5-3* for further
description.
[12] Above speed high See parameter group 5-3* for further
description.
[13] Out of feedb. See parameter group 5-3* for further
range description.
[14] Below feedb. low See parameter group 5-3* for further
description.
[15] Above feedb. high See parameter group 5-3* for further
description.
[16] Thermal warning See parameter group 5-3* for further
description.
[17] Mains out of range See parameter group 5-3* for further
description.
[18] Reversing See parameter group 5-3* for further
description.
[19] Warning See parameter group 5-3* for further
description.
[20] Alarm (trip) See parameter group 5-3* for further
description.
[21] Alarm (trip lock) See parameter group 5-3* for further
description.
[22] Comparator 0 Use the result of comtor 0 in the logic
rule.
[23] Comparator 1 Use the result of comtor 1 in the logic
rule.
[24] Comparator 2 Use the result of comtor 2 in the logic
rule.
[25] Comparator 3 Use the result of comtor 3 in the logic
rule.
[26] Logic rule 0 Use the result of logic rule 0 in the
logic rule.
[27] Logic rule 1 Use the result of logic rule 1 in the
logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the
logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the
logic rule.
[30] SL Time-out 0 Use the result of timer 0 in the logic
rule.
[31] SL Time-out 1 Use the result of timer 1 in the logic
rule.
[32] SL Time-out 2 Use the result of timer 2 in the logic
rule.
[33] Digital input DI18 Use the value of DI18 in the logic rule
(High = TRUE).
®
VLT AQUA Drive Programming Guide
13-02 Stop Event
Option:
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
®
MG20O602 - VLT is a registered Danfoss trademark
Function:
Use the value of DI19 in the logic rule
(High = TRUE).
Use the value of DI27 in the logic rule
(High = TRUE).
Use the value of DI29 in the logic rule
(High = TRUE).
Use the value of DI32 in the logic rule
(High = TRUE).
Use the value of DI33 in the logic rule
(High = TRUE).
This event is TRUE if the frequency
converter is started by any means
(either via digital input, fieldbus or
other).
This event is TRUE if the frequency
converter is stopped or coasted by
any means (either via digital input,
fieldbus or other).
This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and [Reset] is pressed.
This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
This event is TRUE if [OK] is pressed.
This event is TRUE if [Reset] is pressed.
This event is TRUE if [◄] is pressed.
This event is TRUE if [►] is pressed.
▲
This event is TRUE if [ ] is pressed.
▼
This event is TRUE if [ ] is pressed.
Use the result of comtor 4 in the logic
rule.
Use the result of comtor 5 in the logic
rule.
Use the result of logic rule 4 in the
logic rule.
Use the result of logic rule 5 in the
logic rule.
Use the result of timer 3 in the logic
rule.
Use the result of timer 4 in the logic
rule.
Use the result of timer 5 in the logic
rule.
