Danfoss VLT AQUA Drive FC 200 Programming Manual page 99

Parameter Description
13-02 Stop Event
Option:
[73] SL Time-out 6
[74] SL Time-out 7
3 3
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
3.12.3 13-04 Comparators
Comparators are used for comparing continuous variables
(i.e. output frequency, output current, analog input etc.) to
fixed preset values.
Par. 13-10
Comparator Operand
Par. 13-12
Comparator Value
Illustration 3.35
In addition, there are digital values that will be compared
to fixed time values. See explanation in 13-10 Comparator
Operand. Comparators are evaluated once in each scan
interval. Use the result (TRUE or FALSE) directly. All
parameters in this parameter group are array parameters
with index 0 to 5. Select index 0 to programme
Comparator 0, select index 1 to programme Comparator 1,
and so on.
13-10 Comparator Operand
Array [4]
Option:
[0] DISABLED
*
[1] Reference
[2] Feedback
[3] Motor speed
[4] Motor current
[5] Motor torque
[6] Motor power
[7] Motor voltage
[8] DC-link voltage
[9] Motor thermal
[10] Drive thermal
[11] Heat sink temp.
[12] Analog input AI53
98
®
VLT AQUA Drive Programming Guide
Function:
Use the result of timer 6 in the logic
rule.
Use the result of timer 7 in the logic
rule.
Par. 13-11
Comparator Operator
=
TRUE longer than.
. . .
. . .
Function:
Select the variable to be
monitored by the comparator.
MG20O602 - VLT
13-10 Comparator Operand
Array [4]
Option:
[13] Analog input AI54
[14] Analog input AIFB10
[15] Analog input AIS24V
[17] Analog input AICCT
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[30] Counter A
[31] Counter B
[50] Analog input AI53 scaled
[51] Analog input AI54 scaled
13-11 Comparator Operator
Array [6]
Option: Function:
[0] < Select [0] < for the result of the evaluation to be
*
TRUE, when the variable selected in
13-10 Comparator Operand is smaller than the
fixed value in 13-12 Comparator Value. The result
will be FALSE, if the variable selected in
13-10 Comparator Operand is greater than the
fixed value in 13-12 Comparator Value.
[1] ≈ (equal) Select [1] ≈ for the result of the evaluation to be
TRUE, when the variable selected in
13-10 Comparator Operand is approximately equal
to the fixed value in 13-12 Comparator Value.
[2] > Select [2] > for the inverse logic of option [0] <.
13-12 Comparator Value
Array [6]
Range:
Size related [-100000.000 -
*
100000.000 ]
3.12.4 13-2* Timers
Use the result (TRUE or FALSE) from timers directly to
define an event (see 13-51 SL Controller Event), or as
boolean input in a logic rule (see 13-40 Logic Rule Boolean
1, 13-42 Logic Rule Boolean 2 or 13-44 Logic Rule Boolean 3).
A timer is only FALSE when started by an action (i.e. [29]
Start timer 1) until the timer value entered in this
parameter is elapsed. Then it becomes TRUE again.
All parameters in this parameter group are array
parameters with index 0 to 2. Select index 0 to program
Timer 0, select index 1 to program Timer 1, and so on.
®
is a registered Danfoss trademark
Function:
Function:
Enter the 'trigger level' for the
variable that is monitored by
this comtor. This is an array
parameter containing comtor
values 0 to 5.
