Danfoss VLT AQUA Drive FC 200 Programming Manual page 89

Parameter Description
3.9.5 8-5* Digital/Bus
Parameters for configuring the control word Digital/Bus
merging.
NOTE
3 3
These parameters are active only when 8-01 Control Site is
set to [0] Digital and control word.
8-50 Coasting Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-52 DC Brake Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates Start command via the fieldbus/serial
[3] Logic OR
*
8-53 Start Select
Option:
[0] Digital
input
88
VLT
Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
Activates Start command via a digital input.
Activates Start command via the serial
communication port or fieldbus option.
Activates Start command via the fieldbus/serial
communication port, AND additionally via one
of the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTE
Only selection [0] Digital Input is available
when 1-10 Motor Construction is set to [1]
PM, non salient SPM
Activates Start command via a digital input.
Activates Start command via the serial
communication port or fieldbus option.
communication port, AND additionally via one
of the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
Activates Start command via a digital input.
MG20O602 - VLT
®
AQUA Drive Programming Guide
8-53 Start Select
Option:
[1] Bus
[2] Logic AND Activates Start command via the fieldbus/serial
[3] Logic OR
*
8-54 Reversing Select
Option:
[0] Digital
*
input
[1] Bus
[2] Logic AND Activates Reverse command via the fieldbus/
[3] Logic OR
NOTE
This parameter is active only when 8-01 Control Site is set
to [0] Digital and control word.
8-55 Set-up Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates the set-up selection via the fieldbus/
[3] Logic OR
*
8-56 Preset Reference Select
Option:
®
is a registered Danfoss trademark
Function:
Activates Start command via the serial
communication port or fieldbus option.
communication port, AND additionally via one
of the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the frequency converter
reverse function via the terminals (digital
input) and/or via the fieldbus.
Activates Reverse command via a digital input.
Activates Reverse command via the serial
communication port or fieldbus option.
serial communication port, AND additionally
via one of the digital inputs.
Activates Reverse command via the fieldbus/
serial communication port OR via one of the
digital inputs.
Function:
Select control of the frequency converter set-
up selection via the terminals (digital input)
and/or via the fieldbus.
Activates the set-up selection via a digital
input.
Activates the set-up selection via the serial
communication port or fieldbus option.
serial communication port, AND additionally
via one of the digital inputs.
Activate the set-up selection via the fieldbus/
serial communication port OR via one of the
digital inputs.
Function:
Select control of the frequency converter
Preset Reference selection via the terminals
(digital input) and/or via the fieldbus.
