Parameter Description
NOTE
If a feedback is not used, its source must be set to [0] No
Function. 20-20 Feedback Function determines how the
three possible feedbacks will be used by the PID
Controller.
20-01 Feedback 1 Conversion
Option: Function:
[0] Linear
*
[1] Square This parameter allows a conversion function to
root be applied to Feedback 1.
[0] Linear has no effect on the feedback.
[1] Square root is commonly used when a
pressure sensor is used to provide flow
feedback (
flow ∝ pressure )
(
20-02 Feedback 1 Source Unit
Option: Function:
This parameter determines the unit that is used
for this Feedback Source, before applying the
feedback conversion of 20-01 Feedback 1
Conversion. This unit is not used by the PID
Controller.
[0]
*
[1] %
[5] PPM
[10] 1/min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
®
VLT AQUA Drive Programming Guide
20-02 Feedback 1 Source Unit
Option:
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
).
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
NOTE
This parameter is only available when using pressure to
temperature feedback conversion.
If the choice [0] Linear is selected in 20-01 Feedback 1
Conversion, then the setting of any choice in
20-02 Feedback 1 Source Unit does not matter as conversion
will be one-to-one.
20-03 Feedback 2 Source
Option:
[0]
[1]
[2]
[3]
[4]
[7]
[8]
[9]
[10]
[11]
[15]
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
[200] Ext. Closed Loop 1
[201] Ext. Closed Loop 2
[202] Ext. Closed Loop 3
®
MG20O602 - VLT is a registered Danfoss trademark
Function:
Function:
See 20-00 Feedback 1 Source for
details.
No function
*
Analog input 53
Analog input 54
Pulse input 29
Pulse input 33
Analog input X30/11
Analog input X30/12
Analog Input X42/1
Analog Input X42/3
Analog Input X42/5
Analog Input X48/2
