Introduction
1 1
Input polarity of control terminals
12 13 18
Illustration 1.3
12 13 18
Illustration 1.4
NOTE
Control cables must be screened/armoured.
See section on earthing of screened/armoured control
cables in the VLT
correct termination of control cables.
10
VLT
PNP (Source)
Digital input wiring
19 27 29 32 33
NPN (Sink)
Digital input wiring
19 27 29 32 33
®
AQUA Drive Design Guide, MG20N for the
MG20O602 - VLT
®
AQUA Drive Programming Guide
20 37
Illustration 1.5
20 37
1.1.6 Start/Stop
Terminal 18 = 5-10 Terminal 18 Digital Input [8] Start
Terminal 27 = 5-12 Terminal 27 Digital Input [0] No
operation (Default coast inverse)
Terminal 37 = Safe stop (where available)
Speed
Start/Stop
[18]
Illustration 1.6
®
is a registered Danfoss trademark
12 13 18 19 27 29 32 33 20 37
Start/Stop Safe Stop
