Parameter Description
5-12 Terminal 27 Digital Input
Same options and functions as parameter group 5-1*, except for
Pulse input.
Option:
[131] Pump 2 Interlock
[132] Pump 3 Interlock
[133] Pump 4 Interlock
[134] Pump 5 Interlock
[135] Pump 6 Interlock
[136] Pump 7 Interlock
[137] Pump 8 Interlock
[138] Pump 9 Interlock
5-13 Terminal 29 Digital Input
Same options and functions as parameter 5-1*.
Option:
[0] No operation
*
[1] Reset
[2] Coast inverse
[3] Coast and reset inv
[5] DC-brake inverse
[6] Stop inverse
[7] External interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
*
[15] Preset reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[24] Set-up select bit 1
[30] Counter input
[32] Pulse input
[34] Ramp bit 0
[36] Mains failure inverse
[51] Hand/Auto Start
[52] Run permissive
[53] Hand start
[54] Auto start
[55] DigiPot increase
[56] DigiPot decrease
[57] DigiPot clear
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
®
VLT AQUA Drive Programming Guide
5-13 Terminal 29 Digital Input
Same options and functions as parameter 5-1*.
Option:
Function:
[65]
[66]
[78]
[80]
[85]
[120]
[121]
[130]
[131]
[132]
[133]
[134]
Function:
[135]
[136]
[137]
[138]
5-14 Terminal 32 Digital Input
Option:
[0]
5-15 Terminal 33 Digital Input
Option:
[0]
5-16 Terminal X30/2 Digital Input
Option:
[0]
5-17 Terminal X30/3 Digital Input
Option:
[0]
5-18 Terminal X30/4 Digital Input
Option:
[0]
®
MG20O602 - VLT is a registered Danfoss trademark
Reset Counter B
Sleep Mode
Reset Preventive Maintenance Word
PTC Card 1
Latched Pump Derag
Lead Pump Start
Lead Pump Alternation
Pump 1 Interlock
Pump 2 Interlock
Pump 3 Interlock
Pump 4 Interlock
Pump 5 Interlock
Pump 6 Interlock
Pump 7 Interlock
Pump 8 Interlock
Pump 9 Interlock
Function:
No Operation Same options and functions as parameter
*
group 5-1* Digital Inputs, except for Pulse
input.
Function:
No Operation Same options and functions as parameter
*
group 5-1* Digital Inputs.
Function:
No operation This parameter is active when option module
*
MCB 101 is installed in the frequency
converter. Same options and functions as
parameter group 5-1* except for Pulse input
[32].
Function:
No operation This parameter is active when option module
*
MCB 101 is installed in the frequency
converter. Same options and functions as
parameter group 5-1* except for Pulse input
[32].
Function:
No operation This parameter is active when option module
*
MCB 101 is installed in the frequency
converter. Same options and functions as
parameter group 5-1* except for Pulse input
[32].
Function:
