Parameter Description
0-20 Display Line 1.1 Small
Option:
[1611] Power [hp]
[1612] Motor Voltage
3 3
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1622] Torque [%]
[1630] DC Link Voltage
[1632] Brake Energy /s
[1633] Brake Energy /2
min
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Controller State State of the event executed by the
[1639] Control Card
Temp.
28
®
VLT AQUA Drive Programming Guide
Function:
Actual power consumed by the
motor in HP.
Voltage supplied to the motor.
Motor frequency, i.e. the output
frequency from the frequency
converter in Hz.
Phase current of the motor
measured as effective value.
Motor frequency, i.e. the output
frequency from the frequency
converter in percent.
Present motor load as a percentage
of the rated motor torque.
Speed in RPM (revolutions per
minute) i.e. the motor shaft speed
in closed loop based on the entered
motor nameplate data, the output
frequency and the load on the
frequency converter.
Thermal load on the motor,
calculated by the ETR function. See
also parameter group 1-9* Motor
Temperature.
Shows the actual torque produced,
in percentage.
Intermediate circuit voltage in the
frequency converter.
Present brake power transferred to
an external brake resistor.
Stated as an instantaneous value.
Brake power transferred to an
external brake resistor. The mean
power is calculated continuously for
the most recent 120 seconds.
Present heat sink temperature of
the frequency converter. The cut-
out limit is 95 ±5 °C; cutting back in
occurs at 70 ±5 °C.
Percentage load of the inverters
Nominal current of the frequency
converter
Maximum current of the frequency
converter
control
Temperature of the control card.
®
MG20O602 - VLT
0-20 Display Line 1.1 Small
Option:
[1650] External Reference Sum of the external reference as a
[1652] Feedback [Unit]
[1653] Digi Pot Reference View the contribution of the digital
[1654] Feedback 1 [Unit]
[1655] Feedback 2 [Unit]
[1656] Feedback 3 [Unit]
[1658] PID Output [%]
[1659] Adjusted Setpoint
[1660] Digital Input
[1661] Terminal 53
Switch Setting
[1662] Analog Input 53
[1663] Terminal 54
Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42
[mA]
[1666] Digital Output
[bin]
[1667] Pulse Input #29
[Hz]
[1668] Pulse Input #33
[Hz]
[1669] Pulse Output #27
[Hz]
is a registered Danfoss trademark
Function:
percentage, i.e. the sum of analog/
pulse/bus.
Signal value in units from the
programmed digital input(s).
potentiometer to the actual
reference Feedback.
View the value of Feedback 1. See
also parameter group 20-0*.
View the value of Feedback 2. See
also parameter group 20-0*.
View the value of Feedback 3. See
also parameter group 20-0*.
Returns the Drive Closed Loop PID
controller output value in percent.
Displays the actual operating set-
point after it is modified by flow
compensation. See parameter group
22-8*.
Displays the status of the digital
inputs. Signal low = 0; Signal high =
1.
Regarding order, see 16-60 Digital
Input. Bit 0 is at the extreme right.
Setting of input terminal 53. Current
= 0; Voltage = 1.
Actual value at input 53 either as a
reference or protection value.
Setting of input terminal 54. Current
= 0; Voltage = 1.
Actual value at input 54 either as
reference or protection value.
Actual value at output 42 in mA.
Use 6-50 Terminal 42 Output to
select the variable to be
represented by output 42.
Binary value of all digital outputs.
Actual value of the frequency
applied at terminal 29 as a pulse
input.
Actual value of the frequency
applied at terminal 33 as a pulse
input.
Actual value of pulses applied to
terminal 27 in digital output mode.
