Parameter Description

3.24 Main Menu - Analog I/O Option MCB 109 - Group 26

The Analog I/O Option MCB 109 extends the functionality of VLT
additional, programmable analog inputs and outputs. This could be especially useful in Building Management System instal-
lations where the frequency converter may be used as de-central I/O, obviating the need for an outstation and thus
reducing cost.
3 3
Consider the diagram
Analog I/O Carsd
X42 1 2 3
This shows a typical Air Handling Unit (AHU). As can be seen, the addition of the Analog I/O option offers the possibility to
control all of the functions from the frequency converter, such as inlet-, return- and exhaust dampers or heating/cooling
coils with temperature and pressure measurements being read by the frequency converter.
186
T
M
4 5 6 7 8 9 10 11 12
MG.11.CC.02 - VLT
®
VLT HVAC Drive Programming Guide
®
HVAC Drive frequency converters, by adding a number of
M
P T
M
Control Card
12 13 18 19 27 29 32 33 20 37 39 42 50 53 54 55
®
is a registered Danfoss trademark
T
H
Power card
01 02 03 04 05 06
Humidi er steps
or
Cooling steps
