Danfoss VLT AQUA Drive FC 200 Programming Manual page 27

Parameter Description
0-11 Programming Set-up
Option:
3 3
[0] Factory
setup
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Active Set-
*
up
0-12 This Set-up Linked to
Option:
26
VLT
Function:
Select the set-up to be edited (i.e.
programmed) during operation; either the
active set-up or one of the inactive set-ups.
The set-up number being edited is displayed
in the LCP in (brackets).
Cannot be edited but it is useful as a data
source to return the other set-ups to a known
state.
[1] Set-up 1 to [4] Set-up 4 can be edited
freely during operation, independently of the
active set-up.
(i.e. the set-up in which the frequency
converter is operating) can also be edited
during operation. Editing parameters in the
chosen set-up would normally be done from
the LCP, but it is also possible from any of
the serial communication ports.
Function:
This parameter only needs to be programmed if
changing set-ups is required whilst the motor is
running. It ensures that parameters which are
"not changeable during operation" have the
same setting in all relevant set-ups.
To enable conflict-free changes from one set-up
to another whilst the frequency converter is
running, link set-ups containing parameters
which are not changeable during operation.
The link will ensure synchronising of the 'not
changeable during operation' parameter values
when moving from one set-up to another
during operation. 'Not changeable during
operation' parameters can be identified by the
label FALSE in the parameter lists in
4 Parameter Lists.
The 0-12 This Set-up Linked to feature is used
when Multi set-up in 0-10 Active Set-up is
selected. Multi set-up can be used to move
from one set-up to another during operation
(i.e. while the motor is running).
Example:
Use Multi set-up to shift from Set-up 1 to Set-
up 2 whilst the motor is running. Programme
parameters in Set-up 1 first, then ensure that
Set-up 1 and Set-up 2 are synchronised (or
'linked'). Synchronisation can be performed in
two ways:
MG20O602 - VLT
®
AQUA Drive Programming Guide
0-12 This Set-up Linked to
Option:
[0] Not linked
*
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
®
is a registered Danfoss trademark
Function:
1. Change the edit set-up to [2] Set-up 2 in
0-11 Programming Set-up and set 0-12 This Set-
up Linked to to [1] Set-up 1. This will start the
linking (synchronising) process.
0 RPM 0.00A
Set-up Handling
0-12 This Set-up Linked to
Illustration 3.1
OR
2. While still in Set-up 1, using 0-50 LCP Copy,
copy Set-up 1 to Set-up 2. Then set 0-12 This
Set-up Linked to to [2] Set-up 2. This will start
the linking process.
0 RPM 0.00A
Set-up Handling
0-12 This Set-up Linked to
[2] Setup 2
Illustration 3.2
After the link is complete, 0-13 Readout: Linked
Set-ups will read {1,2} to indicate that all 'not
changeable during operation' parameters are
now the same in Set-up 1 and Set-up 2. If there
are changes to a 'not changeable during
operation' parameter, e.g. 1-30 Stator Resistance
(Rs), in Set-up 2, they will also be changed
automatically in Set-up 1. A switch between
Set-up 1 and Set-up 2 during operation is now
possible.
