Danfoss VLT AQUA Drive FC 200 Programming Manual page 31

Parameter Description
0-20 Display Line 1.1 Small
Option:
[2580] Cascade Status
[2581] Pump Status
3 3
[2791] Cascade Reference Reference output for use with
[2792] % Of Total
Capacity
[2793] Cascade Option
Status
[2794] Cascade System
Status
[2795] Advanced
Cascade Relay
Output [bin]
[2796] Extended Cascade
Relay Output [bin]
[2920] Derag Power[kW]
[2921] Derag Power[HP]
[3110] Bypass Status
Word
[3111] Bypass Running
Hours
[9920] HS Temp. (PC1)
[9921] HS Temp. (PC2)
[9922] HS Temp. (PC3)
[9923] HS Temp. (PC4)
[9924] HS Temp. (PC5)
[9925] HS Temp. (PC6)
[9926] HS Temp. (PC7)
[9927] HS Temp. (PC8)
0-21 Display Line 1.2 Small
Option:
[1601] Analog input
*
53
0-22 Display Line 1.3 Small
Option:
[1614] Motor Current The options are the same as those listed
*
0-23 Display Line 2 Large
Option:
30
®
VLT
Function:
Status for the operation of the
Cascade Controller
Status for the operation of each
individual pump controlled by the
Cascade Controller
follower drives.
Readout parameter to show the
system operating point as a %
capacity of total system capacity.
Readout parameter to show the
status of the cascade system.
Function:
Select a variable for display in line 1,
middle position.
The options are the same as those
listed for 0-20 Display Line 1.1 Small.
Function:
Select a variable for display in line 1,
right position.
for 0-20 Display Line 1.1 Small.
Function:
Select a variable for display in line 2.
MG20O602 - VLT
AQUA Drive Programming Guide
0-23 Display Line 2 Large
Option:
[1613] Frequency The options are the same as those listed for
*
0-24 Display Line 3 Large
Option:
[1652] Feedback [Unit] The options are the same as those
*
0-25 My Personal Menu
Array [20]
Range:
Size
related 9999 ]
*
3.2.4 0-3* LCP Custom Readout
It is possible to customize the display elements for various
purposes: *Custom Readout. Value proportional to speed
(Linear, squared or cubed depending on unit selected in
0-30 Custom Readout Unit) *Display Text. Text string stored
in a parameter.
Custom Readout
The calculated value to be displayed is based on settings
in 0-30 Custom Readout Unit, 0-31 Custom Readout Min
Value (linear only), 0-32 Custom Readout Max Value,
4-13 Motor Speed High Limit [RPM], 4-14 Motor Speed High
Limit [Hz] and actual speed.
®
is a registered Danfoss trademark
Function:
0-20 Display Line 1.1 Small.
Function:
listed for 0-20 Display Line 1.1 Small.
Select a variable for display in line 2.
Function:
[0 - Define up to 20 parameters to appear in
the Q1 Personal Menu, accessible via the
[Quick Menu] key on the LCP. The
parameters will be displayed in the Q1
Personal Menu in the order they are
programmed into this array parameter.
Delete parameters by setting the value to
'0000'.
For example, this can be used to provide
quick, simple access to just one or up to
50 parameters which require changing on
a regular basis.
