Parameter Description
23-01 ON Action
Arra [10]
Option: Function:
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A low
[33] Set digital out B low
[34] Set digital out C low
[35] Set digital out D low
[36] Set digital out E low
[37] Set digital out F low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
[81] Derag
NOTE
For choices [32] - [43], see also parameter group 5-3*,
Digital Outputs and 5-4*, Relays.
23-02 OFF Time
Array [10]
Range: Function:
Size [ 0 - Sets the OFF time for the Timed Action.
related 0 ]
NOTE
*
The frequency converter has no back
up of the clock function and the set
date/time will reset to default
(2000-01-01 00:00) after a power
down unless a Real Time Clock
module with back up is installed. In
0-79 Clock Fault it is possible to
program for a Warning in case clock
has not been set properly, e.g. after a
power down.
23-03 OFF Action
Array [10]
See 23-01 ON Action for available actions.
Option:
[0] Disabled
*
®
VLT AQUA Drive Programming Guide
23-04 Occurrence
Array [10]
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
3.20.2 23-1* Maintenance
Wear and tear calls for periodic inspection and service of
elements in the application, e.g. motor bearings, feedback
sensors and seals or filters. With Preventive Maintenance
the service intervals may be programmed into the
frequency converter. The frequency converter will give a
message when maintenance is required. 20 Preventive
Maintenance Events can be programmed into the
frequency converter. For each Event the following must be
specified:
NOTE
To disable a Preventive Maintenance Event the associated
23-12 Maintenance Time Base must be set to [0] Disabled.
Preventive Maintenance can be programmed from the LCP,
but use of the PC-based VLT Motion Control Tool MCT 10
Set-up Software is recommended.
Function:
®
MG20O602 - VLT is a registered Danfoss trademark
Function:
Select which day(s) the Timed Action
applies to. Specify working/non-working
days in 0-81 Working Days,
0-82 Additional Working Days and
0-83 Additional Non-Working Days.
All days
*
Working days
Non-working days
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
•
Maintenance item (e.g. "Motor Bearings")
•
Maintenance action (e.g. "Replace")
•
Maintenance Time Base (e.g. "Running Hours" or
a specific date and time)
•
Maintenance Time Interval or the date and time
of next maintenance
