4.1.19 22-** Application Functions

Par. No. # Parameter description
22-0* Miscellaneous
22-00 External Interlock Delay
22-2* No-Flow Detection
22-20 Low Power Auto Set-up
22-21 Low Power Detection
22-22 Low Speed Detection
22-23 No-Flow Function
22-24 No-Flow Delay
22-26 Dry Pump Function
22-27 Dry Pump Delay
22-28 No-Flow Low Speed [RPM]
22-29 No-Flow Low Speed [Hz]
22-3* No-Flow Power Tuning
22-30 No-Flow Power
22-31 Power Correction Factor
22-32 Low Speed [RPM]
22-33 Low Speed [Hz]
22-34 Low Speed Power [kW]
22-35 Low Speed Power [HP]
22-36 High Speed [RPM]
22-37 High Speed [Hz]
22-38 High Speed Power [kW]
22-39 High Speed Power [HP]
22-4* Sleep Mode
22-40 Minimum Run Time
22-41 Minimum Sleep Time
22-42 Wake-up Speed [RPM]
22-43 Wake-up Speed [Hz]
22-44 Wake-up Ref./FB Difference
22-45 Setpoint Boost
22-46 Maximum Boost Time
22-5* End of Curve
22-50 End of Curve Function
22-51 End of Curve Delay
22-6* Broken Belt Detection
22-60 Broken Belt Function
22-61 Broken Belt Torque
22-62 Broken Belt Delay
22-7* Short Cycle Protection
22-75 Short Cycle Protection
22-76 Interval between Starts
22-77 Minimum Run Time
22-78 Minimum Run Time Override
22-79 Minimum Run Time Override Value
Table 4.22
®
VLT AQUA Drive Programming Guide
Default value
0 s
[0] Off
[0] Disabled
[0] Disabled
[0] Off
10 s
[0] Off
10 s
ExpressionLimit
ExpressionLimit
0.00 kW
100 %
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
60 s
30 s
ExpressionLimit
ExpressionLimit
10 %
0 %
60 s
[0] Off
10 s
[0] Off
10 %
10 s
[0] Disabled
start_to_start_min_on_time
(P2277)
0 s
[0] Disabled
0.000 ProcessCtrlUnit
®
MG20O602 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion
operation index
All set-ups TRUE 0
All set-ups FALSE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE 0
All set-ups TRUE 67
All set-ups TRUE -1
All set-ups TRUE 1
All set-ups TRUE 0
All set-ups TRUE 67
All set-ups TRUE -1
All set-ups TRUE 1
All set-ups TRUE -2
All set-ups TRUE 67
All set-ups TRUE -1
All set-ups TRUE 1
All set-ups TRUE -2
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 67
All set-ups TRUE -1
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups FALSE -
All set-ups TRUE -3
Type
Uint16
4 4
Uint8
Uint8
Uint8
Uint8
Uint16
Uint8
Uint16
Uint16
Uint16
Uint32
Uint16
Uint16
Uint16
Uint32
Uint32
Uint16
Uint16
Uint32
Uint32
Uint16
Uint16
Uint16
Uint16
Int8
Int8
Uint16
Uint8
Uint16
Uint8
Uint8
Uint16
Uint8
Uint16
Uint16
Uint8
Int32
