Parameter Description
3.7.3 5-3* Digital Outputs
Parameters for configuring the output functions for the
output terminals. The 2 solid-state digital outputs are
common for terminals 27 and 29. Set the I/O function for
3
3
terminal 27 in 5-01 Terminal 27 Mode and set the I/O
function for terminal 29 in 5-02 Terminal 29 Mode.
These parameters cannot be adjusted while the motor is
running.
The digital outputs can be programmed with these
functions:
[0]
No operation
[1]
Control ready
[2]
Drive ready
[3]
Drive ready /
remote
control
[4]
Stand-by / no
warning
[5]
Running
[6]
Running / no
warning
[8]
Run on
reference / no
warning
[9]
Alarm
[10]
Alarm or
warning
[11]
At torque
limit
[12]
Out of
current range
[13]
Below
current, low
[14]
Above
current, high
[15]
Out of speed
range
[16]
Below speed,
low
[17]
Above speed,
high
68
®
VLT
AQUA Drive Programming Guide
Default for all digital outputs and relay
outputs
The control board receives supply voltage.
The frequency converter is ready for
operation and applies a supply signal on
the control board.
The frequency converter is ready for
operation and is in Auto On mode.
The frequency converter is ready for
operation. No start or stop command is
been given (start/disable). There are no
warnings.
Motor is running.
The output speed is higher than the speed
set in 1-81 Min Speed for Function at Stop
[RPM]. The motor is running and there are
no warnings.
Motor runs at reference speed.
An alarm activates the output. There are
no warnings.
An alarm or a warning activates the
output.
The torque limit set in 4-16 Torque Limit
Motor Mode has been exceeded.
The motor current is outside the range set
in 4-18 Current Limit.
Motor current is lower than set in
4-50 Warning Current Low.
Motor current is higher than set in
4-51 Warning Current High.
Output speed is outside the range set in
4-52 Warning Speed Low and 4-53 Warning
Speed High.
Output speed is lower than the setting in
4-52 Warning Speed Low.
Output speed is higher than the setting in
4-53 Warning Speed High.
MG20O602 - VLT
[18]
Out of
feedback
range
[19]
Below
feedback low
[20]
Above
feedback high
[21]
Thermal
warning
[25]
Reverse
[26]
Bus OK
[27]
Torque limit
and stop
[28]
Brake, no
warning
[29]
Brake ready,
no fault
[30]
Brake fault
(IGBT)
[35]
External
Interlock
[40]
Out of ref
range
[41]
Below
reference low
[42]
Above
reference
high
[45]
Bus Ctrl
[46]
Bus Ctrl 1 if
timeout
[47]
Bus Ctrl 0 if
timeout
[55]
Pulse output
[60]
Comparator 0 See parameter group 13-1*. If Comparator
[61]
Comparator 1 See parameter group 13-1*. If Comparator
[62]
Comparator 2 See parameter group 13-1*. If Comparator
®
is a registered Danfoss trademark
Feedback is outside the range set in
4-56 Warning Feedback Low and
4-57 Warning Feedback High.
Feedback is below the limit set in
4-52 Warning Speed Low.
The feedback is above the limit set in
4-56 Warning Feedback Low.
The thermal warning turns on when the
temperature exceeds the limit in the
motor, the frequency converter, the brake
resistor, or the thermistor.
Reversing. Logic '1' = relay activated, 24 V
DC when CW rotation of the motor. Logic
'0' = relay not activated, no signal, when
CCW rotation of the motor.
Active communication (no time-out) via the
serial communication port.
Used in performing a coasting stop and in
torque limit condition. If the frequency
converter has received a stop signal and is
at the torque limit, the signal is Logic '0'.
The brake is active and there are no
warnings.
The brake is ready for operation and there
are no faults.
The output is Logic '1' when the brake
IGBT is short-circuited. Use this function to
protect the frequency converter if there is
a fault on the brake modules. Use the
output/relay to cut out the main voltage
from the frequency converter.
External Interlock function has been
activated via one of the digital inputs.
0 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
1 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
2 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
