13-01 Start Event
Option:
[18] Reversing
[19] Warning
3 3
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
96
®
VLT AQUA Drive Programming Guide
Function:
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
Use the result of comtor 0 in the logic
rule.
Use the result of comtor 1 in the logic
rule.
Use the result of comtor 2 in the logic
rule.
Use the result of comtor 3 in the logic
rule.
Use the result of logic rule 0 in the
logic rule.
Use the result of logic rule 1 in the
logic rule.
Use the result of logic rule 2 in the
logic rule.
Use the result of logic rule 3 in the
logic rule.
Use the value of DI18 in the logic rule
(High = TRUE).
Use the value of DI19 in the logic rule
(High = TRUE).
Use the value of DI27 in the logic rule
(High = TRUE).
Use the value of DI29 in the logic rule
(High = TRUE).
Use the value of DI32 in the logic rule
(High = TRUE).
Use the value of DI33 in the logic rule
(High = TRUE).
This event is TRUE if the frequency
converter is started by any means
(either via digital input, field bus or
other).
This event is TRUE if the frequency
converter is stopped or coasted by any
means (either via digital input, fieldbus
or other).
This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and [Reset] is pressed.
MG20O602 - VLT
13-01 Start Event
Option:
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
13-02 Stop Event
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current
range
[8] Below I low
[9] Above I high
[10] Out of speed range
®
is a registered Danfoss trademark
Function:
This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
This event is TRUE if [OK] is pressed.
This event is TRUE if [Reset] is pressed.
This event is TRUE if [◄] is pressed.
This event is TRUE if [►] is pressed.
▲
This event is TRUE if [ ] is pressed.
▼
This event is TRUE if [ ] is pressed.
Use the result of comtor 4 in the logic
rule.
Use the result of comtor 5 in the logic
rule.
Use the result of logic rule 4 in the
logic rule.
Use the result of logic rule 5 in the
logic rule.
Function:
Select the boolean (TRUE or FALSE)
input to deactivate Smart Logic
Control.
Enters the fixed value of FALSE in the
logic rule.
Enters the fixed value TRUE in the
logic rule.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
See parameter group 5-3* for further
description.
