Starting/Stopping the Measurement

1.5 Starting/Stopping the Measurement
Starting a measurement
START
Pressing the
• Waveform data displayed on the screen is cleared once the measurement starts.
• You can also start the measurement by inputting signal into the external control terminal.
Refer to "10 Controlling the Instrument Externally" (p. 179).
Waveform display during measurement
In general, the waveforms are displayed after the specified recording length of data has been
acquired. When the measurement is performed at a relatively slow speed, the waveforms are
displayed while the data is being acquired.
However, even if a slow-speed range is set, the waveforms are displayed after the data of the
whole waveform has been acquired, depending on the overlay or magnification setting.
To save data automatically during measurement
Refer to "Saving waveform data automatically" (p. 68).
Stopping the measurement
Pressing the STOP
length have been acquired.
Pressing the STOP
20
key starts a measurement.
key once stops the measurement after the waveforms of the specified recording
key twice stops the measurement immediately.
