Operating the Waveform Screen
2
and Analyzing Data
You can analyze measured data with various functions including trace cursor measurement and
search of input waveforms on the waveform screen. You can also change measurement conditions
or other configuration on this screen.
Operation available on the waveform screen
Use the trace cursors
• Reading measured values (p. 22)
Moving the waveform display position
• Moving waveforms by dragging them
• Moving waveforms with the scroll bar
Use the section cursors
• Specifying the waveform range (p. 26)
Changing the display magnification of
waveforms
• Magnifying/demagnifying waveforms (p. 32)
• Magnifying a part of waveforms horizontally
(p. 37)
