Configuring Measurement Conditions
Update rate of each module
The data update rate is not allowed to exceed the maximum sampling rate of each module.
The same data are measured until they get updated, causing the instrument to plot a stair-step
waveform.
In addition, even though the same signal is measured simultaneously, values may vary due to
differences in the sampling rate, frequency range, and frequency characteristics of modules.
Module
Model 8966 Analog Unit
Model 8967 Temp Unit
Model 8968 High Resolution Unit
Model U8969 Strain Unit
Model 8970 Freq Unit
Model 8971 Current Unit
Model 8972 DC/RMS Unit
Model 8973 Logic Unit
MR8990
Digital Voltmeter Unit
Model U8974 High Voltage Unit
Model U8975 4ch Analog Unit
Model U8976 High Speed Analog Unit
8
Sampling rate of module
20 MS/s (50 ns)
Varies according to the data refresh
setting.
1 MS/s (1 µs)
200 kS/s (5 µs)
Varies according to the setting.
1 MS/s (1 µs)
Varies according to the response setting.
20 MS/s (50 ns)
Varies according to the NPLC setting.
1 MS/s (1 µs)
5 MS/s (200 ns)
200 MS/s (5 ns)
Reference
–
p. 52
–
p. 54
p. 56
p. 59
p. 61
–
p. 62
p. 64
–
–
