Hioki Memory HiCorder MR6000 Instruction Manual page 101

The behavior related to the
conditions (AND and OR).
With OR In
Out
With AND In
Out
in and out triggers varies depending on the trigger logical
window- window-
The window-trigger condition is satisfied when the input signal crosses the
upper or lower limit value of the threshold (level) and thereby falls within the
range, which is specified by the upper and lower limit values of the threshold
(level).
The window-trigger condition is satisfied when the input signal crosses the
upper or lower limit value of the threshold (level) and thereby gets out of the
range, which is specified by the upper and lower limit values of the threshold
(level).
The window-trigger condition is satisfied when the input signal is inside the
range, which is specified by the upper and lower limit values of the threshold
(level).
The window-trigger condition is satisfied when the input signal is outside the
range, which is specified by the upper and lower limit values of the threshold
(level).
Triggering the Instrument Using Analog Signals
5
97
