Hioki Memory HiCorder MR6000 Instruction Manual page 4

Contents
5.8 Triggering the Instrument at
Regular Intervals
(Interval Trigger) ........................... 104
5.9 Triggering the Instrument
Externally (External Trigger) ....... 106
5.10 Triggering the Instrument
Manually (Forcible Trigger) ......... 106
6
Search Function
6.1 Searching For Peak Values ......... 108
6.2 Searching For the Positions
Where Trigger Condition Is
Satisfied .........................................110
6.3 Searching For Differences from
the Fundamental Wave
(Memory HiConcierge) ..................114
6.4 Allowing the Display to Jump to
the Specified Position ...................116
7
Numerical Calculation
Function
7.1 Numerical Calculation
Procedure ..................................... 120
7.2 Setting Numerical Calculation .... 122
„ Displaying the numerical calculation
results .......................................................131
7.3 Evaluating the Calculation
Results on a Pass/Fail Basis ....... 132
„ Displaying the evaluation results and
outputting signals externally .....................135
7.4 Numerical Calculation Types
and Descriptions .......................... 136
8
Setting the System
Environment
9
Connecting the
Instrument to PCs
9.1 Configuring the LAN Settings
and Connecting to the
Network ......................................... 150
„ Configuring the LAN settings with the
instrument .................................................150
9.2 Managing Data in the Instrument
With the FTP Server Function .... 155
„ Setting the FTP sever with the
instrument .................................................156
„ Operating the instrument with a PC
(FTP server function) ................................157
ii
9.3 Sending Data to a PC With the
FTP Client Function ..................... 158
„ Setting up an FTP server on a PC ............159
„ Setting the FTP client with the
instrument .................................................163
9.4 Operating the Instrument with a
Browser Installed in a PC ............ 164
„ Connecting the PC to the instrument
with Internet browser ................................165
107
„ Operating the instrument remotely ...........166
„ Starting/Stopping the instrument ..............167
„ Setting the comment .................................168
„ Acquiring data from the instrument ...........169
„ Setting the clock .......................................170
„ Handling files ............................................170
9.5 Sending Emails ............................ 171
„ Configuring the basic setting for sending
email .........................................................172
„ Setting email contents ..............................173
„ Setting authentication, compression,
and encryption for emails to be sent .........174
9.6 Controlling the Instrument with
Command Communications
119
(LAN) ............................................. 176
10
Controlling the
Instrument Externally 179
10.1 External Input and Output ........... 180
„ External input (IN1), (IN2) .........................180
„ External output (OUT1), (OUT2) ...............181
„ Trigger output (TRIG.OUT) .......................183
„ External trigger terminal (EXT.TRIG) ........185
10.2 External Sampling
(EXT.SMPL) ................................... 187
11
Appendix
143
11.1 Information for Reference
Purposes ....................................... 189
„ Waveform file size (for reference) .............189
„ Maximum recording time when the
149
real-time save is on (reference) ................193
„ Scaling method for strain gauges .............199
„ Example of a waveform text file ................200
Index
189
Ind.1
