Search Function - Hioki Memory HiCorder MR6000 Instruction Manual

6

Search Function

Using the search function allows you to search measured waveform data for positions where user-
defined search conditions have been satisfied.
>
Operation available on the search screen
Peak search
You can searches for the maximum, minimum, local maximum (maximal), or local minimum (minimal)
value. Select one of them. (p. 108)
Trigger search
You can searches for the position where the specified trigger condition is satisfied. Set the trigger
condition. (p. 110)
Memory HiConcierge
You can detects differences from the fundamental wave automatically based on the histogram or
standard deviation. Set the fundamental wave. (p. 114)
Jump
The display can jump to the specified time, trace cursor position, section cursor position, event number,
trigger point, or search mark. (p. 116)
