Triggering the Instrument at Regular Intervals (Interval Trigger)

5.8 Triggering the Instrument at Regular Intervals
(Interval Trigger)
The start trigger can be activated at specified intervals. Setting the recording mode to
allows the instrument to record waveforms at regular intervals.
• When using the pre-trigger, the instrument starts monitoring the time of the interval trigger after
the first pre-trigger time elapses since the start of measurement.
• No start triggers are activated by any interval triggers while the instrument is filling the pre-trigger
memory. The interval trigger triggers the instrument while the instrument is waiting for a trigger
after the pre-trigger time has elapsed.
• Since the clock is corrected internally, displayed trigger times may not synchronize with the
intervals of the interval trigger.
> [Trigger] > [Common]
2
3
1
1
Tap [Interval trigger].
2
Set [Interval trigger]
3
Enter the interval (in terms of [h], [min], and [s]).
The internal trigger is generated at the start of the measurement, and they are repeatedly generated at the
specified intervals.
104
to [On] or [Off].
[Repeat]
