Setting the Trigger

The trigger function allows the instrument to start and stop recording using specific signals. When
recording is started or stopped by specific signals, it is referred to as "the instrument is triggered" or
"the start/stop trigger is activated."
When the real-time save is set to [On], the trigger function cannot be used.
In this chapter, the mark
the point the stop trigger is activated.
In the descriptions of each trigger source, the mark
satisfied and the point each trigger is generated.
> [Trigger] > [Common]
Operation available on the
Setting the trigger
• Trigger timing (p. 84)
• Pre-trigger, post-trigger (p. 86)
• Trigger logical condition (logical AND or OR)
among the trigger sources (p. 91)
Setting the interval trigger
Setting the external trigger
Forcible trigger
Trigger output
represents the point the start trigger is activated; the mark
[Trigger] screen
Setting the trigger sources
Setting the analog trigger
• Level trigger
• Window trigger
• Period trigger
• Glitch trigger
• Voltage drop trigger
Setting the logic trigger
(p. 104)
• Logic-trigger conditions
• Trigger filter
(p. 106)
• Trigger pattern
(p. 106)
(p. 183)
represents the point each trigger condition is
represents
5
(p. 93)
(p. 102)
81
