Capture high- to low-voltage signals in a single device
Rugged, Professional and Ready for the Field
MEMORY HiCORDER
CAT III 600 V
insulation performance
• Maximum 600V AC/DC input - no need for a differential probe
• 4 completely isolated channels let you simultaneously record
data on a 3-phase power line plus have one extra channel
Tough against harsh environments
• Operating temperature range:
• Built to withstand mechanical shocks and vibrations
(ships standard with side protectors)
Make settings easily with
Simply select what you'd like to measure and follow the on-
screen instructions to select the appropriate settings. The re-
corder can be easily configured to measure voltage drops and
power outages.
MR8880
Recorders
-10°C to 50°C
PRESETS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MR8880 and is the answer not in the manual?

Questions and answers

Related Manuals for Hioki MR8880

Summary of Contents for Hioki MR8880

  • Page 1 MEMORY HiCORDER MR8880 Recorders Capture high- to low-voltage signals in a single device Rugged, Professional and Ready for the Field CAT III 600 V insulation performance • Maximum 600V AC/DC input - no need for a differential probe • 4 completely isolated channels let you simultaneously record...
  • Page 2 Safe & Reliable Measurement The MR8880 offers safe, reliable operation featuring CAT III 600 V isolated inputs in a compact yet durable design that excels at taking measurements in harsh environments. Direct input and measurement of 3-phase power lines CAT III 600 V isolated inputs (4 channels) n 4 analog + 8 logic channels n Directly input 600 V AC/DC (CAT III) and 300 V AC/DC (CAT IV) input.

  • Page 3: Other Convenient Functions

    Settings are as Easy as 1-2-3 with PRESETS To configure the MR8880, you need only select what you’d like to measure—“Measure a commercial power supply,” “Monitor a power source for a voltage drop,” etc.—and follow the on-screen instructions to select the appropriate set- tings.
  • Page 4 Applications The MR8880 provides a turnkey solution for both high-speed measurement at 1 MS/s and long-term measure- ment. Its ability to measure everything from high- to low-voltage signals allows it to play an important role in a variety of measurement scenarios.
  • Page 5 Functionality and Performance The MR8880 delivers convenient functionality designed to maximize ease of use along with exceptional performance. See how this instrument can transform your concern and discontent to peace of mind and satisfaction. Take home data for later Data can be saved directly viewing on a computer to external media.

  • Page 6: Basic Specifications

    600 V AC, DC CAT III / 300 V AC, DC CAT IV 3) HIOKI sensor: Set HIOKI clamp-on probe and range value. Max. rated voltage to (with input isolated from the unit, the maximum voltage that can be applied between 4) Output rate setting: Select scaled value per 1 V from a list.

  • Page 7: Appearance And Dimensions

    PRINTER UNIT MR9000 attached • Zero adjustment can be performed for all channels and ranges at once. n PC Software Specifications Bundled with the MR8880 in the CD-R Wave Viewer (Wv) Software • Simple display of waveform file • Text conversion: convert binary data file to text format, with...
  • Page 8 1kV AC/DC 500 A to 1000 A *For commercial power lines, 50/60Hz (separate power supply not required) *For P9000. Inquire with your Hioki distributor. CLAMP ON PROBE 9018-50 Bus powered USB cable Excellent phase characteristics, Input from 10 to USB(A)- Micro B cable 500 A, 40 Hz to 3 kHz for 0.2 V AC output, BNC...
