External Input and Output
100 kΩ
When the auto-range function is used, the instrument is triggered, outputting the TRIG OUT signal. Be careful
when performing auto-range measurement while using the TRIG OUT signals.
184
5 V
High
4.0 V to 5.0 V
10 kΩ
TRIG OUT
Low
0 V to 0.5 V
GND
Pulse width
