Host Application Objects
9.4

Sync Object (EEh)

Category
Extended
Object Description
The Anybus CompactCom 40 EtherNet/IP does not support CIP Sync. This object is only used to store the
cycle time for the last established IO connection that consumes data.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
The attributes are represented on EtherNet/IP as follows:
# Name
1 Cycle time
2–8 (not implemented)
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
Get_Attribute
Get_Attribute
Set_Attribute
Access Data Type
Get/Set UINT32
Description
The RPI for the last established IO connection that consumes
data (O→T RPI)
87 (144)
SCM-1202-019-EN 1.6
