Anybus Module Objects
10.4

Network Object (03h)

Category
Basic
Object Description
For more information regarding this object, consult the general Anybus CompactCom 40 Software Design
Guide.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance
number
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
Basic
# Name
1 Network type
2 Network type string
3 Data format
4 Parameter data
support
-
5 - 7
®
Anybus CompactCom ™ 40 Common Ethernet Design Guide
Get_Attribute
Get_Attribute
Set_Attribute
Get_Enum_String
Map_ADI_Write_Area
Map_ADI_Read_Area
Map_ADI_Write_Ext_Area
Map_ADI_Read_Ext_Area
Access Data Type
Get Array of
CHAR
Get UINT8
Get UINT16
Get UINT16
Access Type
Get UINT16
Get Array of
CHAR
Get ENUM
Get BOOL
- -
Value
"Network"
02h
01h
01h
Value
00A3h
"Common Ethernet"
00h (LSB first)
False
Consult the general Anybus CompactCom 40 Software Design
Guide for further information.
57 (104)
HMSI-27–269 2.1
