CIP Objects
7.13

Port Object (F4h)

Category
Extended
Object Description
The Port Object describes the CIP ports present on the device. Each routable CIP port is described in a sepa-
rate instance. Non-routable ports may be described. Devices with a single CIP port are not required to sup-
port this object.
The object exists only if enabled in the EtherNet/IP Host Object (Instance Attribute #17).
See also ..
• EtherNet/IP Host Object (F8h), p. 88
• CIP Port Configuration Object (0Dh), p. 74
Supported Services
Class:
Instance:
Class Attributes
# Name Access
1 Revision Get
2 Max Get
Instance
3 Number of Get
Instances
8 Entry Port Get
9 Port Instance Get
Info
Anybus CompactCom 40 EtherNet/IP Transparent Ethernet Network Guide
(Anybus Module Object)
(Host Application Object)
Get_Attributes_All
Get_Attribute_Single
Get_Attributes_All
Get_Attribute_Single
Type Value
UINT 0002h (Object revision)
UINT Max. instance number
UINT Number of ports currently created.
UINT Returns the instance of the Port Object that describes the port through
which this request entered the device.
Array of: Array of structures containing instance attributes 1 and 2 from each in-
stance. The array is indexed by instance number, up to the maximum
number of instances. The value at index 1 (offset 0) and any non-instanti-
ated instances will be zero.
Struct of: Enumerates the type of port (see instance attribute #1)
UINT (Type) CIP port number associated with this port (see instance attribute #2)
UINT
(Number)
48 (144)
