CIP Objects
10.6

Connection Manager (06h)

Category
Extended
Object Description
This object is used for connection and connectionless communications, including establishing connections
across multiple subnets.
Supported Services
Class:
Instance:
Class Attributes
(No supported class attributes)
Instance Attributes
# Name Access
1 Open Set
Requests
2 Open Format Set
Rejects
3 Open Re- Set
source
Rejects
4 Open Other Set
Rejects
5 Close Set
Requests
6 Close For- Set
mat Rejects
7 Close Other Set
Rejects
8 Connection Set
Timeouts
Anybus CompactCom 40 EtherNet/IP Network Guide
-
Get Attribute All
Get Attribute Single
Set Attribute Single
Large_Forward_Open
Forward_Open
Forward_Close
Unconnected Send (when unconnected routing is enabled)
Type Value/Description
UINT Number of Forward Open service requests received.
UINT Number of Forward Open service requests which were rejected due to
bad format.
UINT Number of Forward Open service requests which were rejected due to
lack of resources.
UINT Number of Forward Open service requests which were rejected for rea-
sons other than bad format or lack of resources.
UINT Number of Forward Close service requests received.
UINT Number of Forward Close service requests which were rejected due to
bad format.
UINT Number of Forward Close service requests which were rejected for rea-
sons other than bad format.
UINT Total number of connection timeouts that have occurred in connections
controlled by this Connection Manager.
