Secton 6 - Electrcal System
MEASURING #
• This message is displayed when the platform is stopped during either STATIC phase, when the
GP400 takes a measurement.
• There will be a short delay while the machine is allowed to stabilize after movement is stopped.
MUST GO DOWN!
• This message occurs if the wrong switch is operated when the GP400 is waiting for the platform
to be lowered.
MUST GO UP!
• This message occurs if the wrong switch is operated when the GP400 is waiting for the platform
to be raised.
PLATFORM DOWN?
• This message is prompting for confirmation that the platform is fully lowered. If necessary the
DOWN switch can be activated to lower the platform.
• Press ENTER to confirm when the platform is fully lowered.
PLATFORM EMPTY?
• This message is prompting for confirmation that the platform is completely empty.
• Press ENTER to confirm when the platform is empty.
PLATFORM LOADED?
• This message is prompting for confirmation that the platform is loaded to rated load: 1500 lbs
(US/CSA), 680 Kgs (CE/AU). (100% of the load rating listed on the serial plate).
• Press ENTER to confirm when the platform is loaded.
PLEASE LIFT ...
• This message is prompting for the platform to be raised.
• The UP switch should be operated.
PLEASE LOWER ...
• This message is prompting for the platform to be lowered.
• The DOWN switch should be operated.
PLEASE WAIT
• This message indicates that the is busy; the delay will be short (no more than 5s).
REDO DYNAMIC:
• This message is displayed if the DYNAMIC phase of load calibration has previously been
completed.
• Press ENTER when "NO" is displayed if there is no need to redo the DYNAMIC phase.
• Press UP or DOWN to display "YES" then press ENTER if it is necessary to redo the DYNAMIC
phase.
• If the previous DYNAMIC calibration was in error, or if the height or pressure sensor is replaced,
it will be necessary to redo the DYNAMIC phase.
REDO EMPTY:
• This message is displayed if the EMPTY phase of load calibration has previously been
