Mec Speed Level Series Service & Parts Manual page 108

Secton 8 - Troubleshootng - 3084RT Models
Selection ID
2A-15a
2A-15b
Sub Menu
2A-15c
2B-1
2B-2
2B-3
2B-4
2B
PLATFORM 2B-5
2B-6
2B-7
2B-8
2B-9
2C-1
2C-2
2C
2C-3
GROUND
2C-4
2C-5
2D-1
2D-2
2D-3
2D-4
2D-5
2D
2D-6
INPUTS
2D-7
2D-8
2D-9
2D-10
2D-11
2E
ANALOGS
Page 101
EZ-Cal Readout
Level / Off Level Status of axle position as read by GP400 - Not used on all models
Status of oscillating axle lock valves, locked = no oscillation - Not
Locked Y/N
used on all models
Position of oscillating Axle relative to the chassis - Not used on all
Angle
models
Trigger ON/OFF Current status of enable trigger - upper controls
DLD Status of Lift/Drive selector switch
Indicates % of stroke from center in real time. Direction not
Joystick
indicated here
FWD/DWN OFF/
Status of Forward micro-switch Forward stroke of the joystick
ON
REV/UP OFF/ON Status of Reverse micro-switch Reverse stroke of the joystick
LEFT OFF/ON Status of Left Steer switch
RIGHT OFF/ON Status of Right Steer switch
Status of rear wheel solenoids activation. Activated in high speed or
Positrac Y/N
elevated drive
EMSG OFF/ON Not used
UP OFF/ON Status of Up switch from lower control station
DOWN OFF/ON Status of Down switch from lower control station
OUT OFF/ON Not used
IN OFF/ON Not used
EMSg OFF/ON Not used
P7-1 12 Volt Supply. Battery voltage from TBM Module
P7-2 Base Selected. ON= Base/Platform select switch in Base position
P7-3 Up. On= platform UP switch activated to elevate platform
Platform Selected. ON= Base/Platform selector switch in Platform
P7-4
position.
Limit Switch. ON= limit switch closed - platform low enough to be in
P7-5
stowed position
P7-7 Down. ON= Down switch activated for platform lower operation
P79 Throttle Solenoid. ON= Throttle requested by function operation
Choke (gas engine) or pre-heat (diesel). ON= Choke or Pre-heat
P7-10
switch activated
Axle Center Switch. ON= Front axle parallel with chassis - Elevated
P7-11
drive enabled
P7-12 Start. ON= input from engine-start switch
P7-13 Oil Pressure Switch
Not used Not used
Speed Level Seres - Servce & Parts Manual
Explanation
January 2019
