Mec Speed Level Series Service & Parts Manual page 41

Secton 5 - Hydraulc System
1
4
TORQUE
SEQUENCE
5
2
7
PRE-TORQUE = 10 FT LBS
FINAL TORQUE = 50 FT LBS
25
26
15
37
1
DT710 BRAKE MOTOR COMPONENTS
1. * Dust Seal
2. * Metal Backup Shim
3. * Backup Seal
4. * Shaft Seal
5. * Small Piston O-Ring Seal
6. * Small Piston Seal
7. * Large Piston O-Ring Seal
8. * Large Piston Seal
9. * O-Ring Seal
10. * Body Seals (3)
11. * Manifold Seal
12. * Commutator Seal
13. * O-Ring Seal
14. * Backup Seal
15. Housing
16. Shaft Bearing
17. Friction Disks (10)
18. Disk Stampings (9)
19. Thick Disk Stampings (2)
*Seal kit components
Page 34
6
3
13
12
11
10
29
28
27
18
17
36
16
3
35
4
2
20. Piston
21. Springs (25)
22. Spacer Shims (1–3)
23. Rear Housing
24. Capscrews (8)
25. Drive Link Spacer
26. Drive Link
27. Rotor Assembly
28. Manifold
29. Commutator Assembly
30. Endcover Piston
31. Piston Spring
32. Endcover
33. I.D. Tag Assembly
34. Assembly Bolts (7)
35. Shaft
36. Shaft Key
37. Shaft Nut
Speed Level Seres - Servce & Parts Manual
34
31
33
32
10
14
30
20
8
6
19
7
5
15.7 mm .620 in.
16 mm .630 in.
Front Housing
January 2019
"V" Marks for Reassembly
24
22
16
9
21
Rear Housing Mounting Surface
Piston
2 3
1
15
23
4
16
