Mec Speed Level Series Service & Parts Manual page 279

Secton 16 - Base
Item Part Number
1 REF
2 16154
3 14896
4 25429
5 16226
6 90749
7 16229
8 8841
9 91658
10 19276
93173
11
93174
12 91745
13 8368
14 9370
15 6121
16 91633
17 93093
18 50237
19 50048
20 50028
21 50068
22 50047
23 50150
24 HDW9200
25 HDW7778
26 HDW8267
27 50282
28 50061
Page 272
Control Module Weldment -- See "Module Installation" On Page 270
Bracket, Cross Support
Block, Slide, Door
Pad
Bracket, Control Box
Plug, Battery Charger Connection
Bracket, Battery Disconnect
Switch, Battery Disconnect
Motor Controller
Heat Sink
Fuse
Base
Contactor, Solenoid 48V, 12V Coil
Diode
Fluid Level Gauge
Trim Lock
Battery Charger
Manifold, Leveling -- See Section 5 - Hydraulics
Screw, Hex M8 x 100
Nut, M8 Nylock
Screw, Hex, M6 x 20
Washer, M6 Fender
Nut, M6 Nylock
Screw, 5/16–18 × ¾, GR5
Plug, ¼ NPT
Screw, FPH MS 1/4-20 x 12
Nut,Top Lk 1/4-20 GR C
Screw, Hex, M8 x 35
Washer, 5/16 Flat
REF - Reference
Speed Level Seres - Servce & Parts Manual
Description
January 2019
Qty������
--
1
4
2
2
1
1
1
1
1
1
1
1
1
1
5 ft.
1
1
3
6
14
15
14
4
1
2
2
2
4
