Mec Speed Level Series Service & Parts Manual page 233

Secton 14 - Axles
Item Part Number
91166
91168
1 91578
91580
91581
91165
91167
2 91577
91579
91581
Incl 91180
3 50165
4 REF
5 19162
6 19087
7 18074
8 --
9 50033
10 19119
11 19120
12 18152
13 50039
14 50006
15 50007
16 18151
17 50027
18 50068
Page 226
Wheel/Tire Assy, LH - 10 PLY - Pneumatic (ANSI Standard)
Wheel/Tire Assy, LH - 10 PLY - Foam (ANSI Option) (CE Standard)
Wheel/Tire Assy, LH - Non-Marking Pneumatic (ANSI Option)
Wheel/Tire Assy, LH - Non-Marking Foam (ANSI, CE Option)
Wheel/Tire Assy, LH - Turf Pneumatic (ANSI Option)
Wheel/Tire Assy, RH - 10 PLY - Pneumatic (ANSI Standard)
Wheel/Tire Assy, RH - 10 PLY - Foam (ANSI Option) (CE Standard)
Wheel/Tire Assy, RH - Non-Marking Pneumatic (ANSI Option)
Wheel/Tire Assy, RH - Non-Marking Foam (ANSI, CE Option)
Wheel/Tire Assy, RH - Turf Pneumatic (ANSI Option)
Wheel (Service, No Tire)
Nut, Lug, ½" - 20, GR 5
Front Axle Assembly
Cover
Cylinder, Axle Lock
Pin, Ø1.25"
--
Bolt, M10 x 25
Pin, Ø1.25
Pin, Ø7.0
Pin Retainer, 0.5 x 3.80
Bolt, M12 x 30
Lock Washer, M12
Lock Washer, M10
Pin Retainer, .375 x 3.75
Bolt, M6 x 10
Washer, M6 Flat
REF - Reference
Incl - Included with Assembly
Speed Level Seres - Servce & Parts Manual
Description
January 2019
