Mec Speed Level Series Service & Parts Manual page 109

Secton 8 - Troubleshootng - 3084RT Models
Selection ID
2F-1
2F-2
2F-3
2F-4
2F-5
2F-6
2F-7
2F-8
2F-9
2F-10
2F-11
2F-12
2F-13
2F
2F-14
OUTPUTS
2F-15
2F-16
2F-17
2F-18
2F-19
2F-20
2F-21
2F-22
2F-23
2F-24
2F-25
2G-1
2G
2G-2
LOG
2G-3
Page 102
EZ-Cal Readout
Choke (gas engine) or pre-heat (diesel). ON= Choke or Pre-heat
P4-1
activated
P4-2 Engine Start. ON= Starter activated
P4-4 Throttle Solenoid. ON= Throttle solenoid pulled in
P4-5 Fuel to fuel select switch. ON= fuel system activated
P4-6 Fuel to fuel select switch. ON= fuel system activated
P4-7 Alternator Excite. ON= power to activate alternator charge
P4-8 Ignition. ON= power to ignition coil (gas) or fuel hold solenoid (diesel)
Rear Wheel Bi-pass Valves. ON= Valves powered, rear wheels in
P4-10
bi-pass
Proportional Valve. ON= Proportional valve activated for lift and drive
P4-12
operation
Down Valves. ON= Down valves activated for platform lower
P4-14
operation
P5-1 Lift Valve. ON= Lift valve activated for platform Lift
P5-2 Steer Right. ON= steer right valve activated
P5-3 Steer Left. ON= steer left valve activated
P5-4 Drive Forward. ON= drive forward valve activated
P5-5 Drive Reversed. ON= drive reverse valve activated
Alarm. ON= alarm activated (default alarm in Down, may be selected
P5-6
for other modes)
High Torque. ON= high torque valve activated (drive range toggle in
P5-7
down position)
High Speed. ON= high speed valve activated (drive range toggle in
P5-8
up position)
P5-9 Hour Meter. ON= Meter powered up
Power Supply to limit switch and TBM module - should be ON when
P5-12
system powered
Rear Pitching Valve. ON= rear pitching valve activated for Platform
P6-1
Rear Leveling
Front Pitching Valve. ON= Front Pitching valve activated for Platform
P6-2
forward Level
P6-3 Outrigger – Not used
P6-4 Left Rolling Valve. ON= Left valve activated for platform Level Left
P6-11 Axle Lock Valves. ON= Axle valves powered, front axle will oscillate
Cal Date Date of Load Sense calibration (CE option only)
Software MEC specific software version
Powered Accumulated time GP400 powered up (red LED on)
Speed Level Seres - Servce & Parts Manual
Explanation
January 2019
