Mec Speed Level Series Service & Parts Manual page 322

Secton 17 - Decals, ANSI Models
Decals, RT Models, ANSI Specification - Part 1
1
5 5 5
6
9 9 9
2684
12 12 12
12
3084
WARNING
MAXIMUM PLATFORM CAPACITY - EVENLY DISTRIBUTED
1500 LBS
680 kg
5-PERSONS
15 15 15
91850
17 17 17
LOCATE CONTROL BOX HERE
FOR NORMAL OPERATION OF THIS UNIT
7155
21
THIS MACHINE HAS BEEN CONSTRUCTED
IN ACCORDANCE WITH CAN B354.2-01.
Sigma Level
ART_3128
Page 315
3084RT
2
2684RT
7 7 7
INSPECT MACHINE AND MAKE SURE THAT IT IS OPERATING PROPERLY,
THAT ALL NAME PLATE AND SAFETY AND CONTROL DECALS ARE IN PLACE
AND LEGIBLE, AND THAT THE MACHINE IS IN ACCORDANCE WITH THE
MANUFACTURER'S MAINTENANCE REQUIREMENTS CONTAINED IN THE
OPERATION AND MAINTENANCE MANUAL AND THE DAILY SAFETY CHECKLIST.
OPERATE MACHINE WITH EXTREME CAUTION. WATCH FOR OBSTRUCTIONS
WHICH MAY STRIKE PLATFORM, PERSONNEL, CONTROLS, OR MACHINE.
OPERATE CONTROLS SLOWLY FOR SMOOTH PLATFORM MOTION.
FOR DRIVING WITH PLATFORM LOWERED:
DO NOT EXCEED MAXIMUM PLATFORM OR
EXTENSION LOAD LIMIT CAPACITY.
LOAD TO BE UNIFORMLY DISTRIBUTED.
PLACE LOAD NEAR CENTER OF PLATFORM
WHEN POSSIBLE.
DO NOT DRIVE ON SIDE SLOPE IF PLATFORM
IS OVER 5% OFF LEVEL.
DO NOT DRIVE UP OR DOWN A GRADE OF
OVER 40%.
FOR DRIVING WITH PLATFORM ELEVATED:
DRIVE ONLY ON A SMOOTH, FIRM, AND PLANAR
SURFACE FREE OF OBSTRUCTIONS.
DO NOT EXCEED MAXIMUM PLATFORM OR
EXTENSION LOAD CAPACITY.
LOAD MUST BE UNIFORMLY DISTRIBUTED.
IF TILT WARNING LIGHT ILLUMINATES OR
TILT ALARM SOUNDS LOWER PLATFORM
AND RE-LEVEL
USE EXTREME CAUTION.
IMPROPER OPERATION OF THIS MACHINE
COULD CAUSE DEATH OR SERIOUS INJURY.
SIDE LOAD
250 LBS
1100 N
91847
16 16 16
7156
Speed Level Seres - Servce & Parts Manual
8 8 8
OTHER HAZARDS
1. DO NOT EXCEED PLATFORM LOAD CAPACITY.
2. DO NOT EXCEED MAXIMUM SIDE FORCE AND
MAXIMUM NUMBER OF OCCUPANTS.
3. DO NOT USE WITHOUT GUARD RAILS IN PLACE,
AND ENTRY GATE PROPERLY SECURED.
4. DO NOT USE IF WORK PLATFORM IS NOT WORKING
PROPERLY OR IF ANY PART IS DAMAGED OR WORN.
5. DO NOT USE NEAR MOVING VEHICLES OR CRANES.
6. DO NOT STAND OR SIT ON GUARDRAILS,
ALL PERSONNEL SHALL ALWAYS MAINTAIN FIRM
FOOTING ON PLATFORM FLOOR.
7. DO NOT USE WHILE UNDER THE INFLUENCE OF
ALCOHOL OR DRUGS.
8. DO NOT OVERRIDE SAFETY DEVICES.
9. DO NOT LEAVE MACHINE UNATTENDED WITH KEY
IN THE SWITCH.
10. DO NOT RAISE PLATFORM WHILE MACHINE IS ON
A TRUCK, FORKLIFT, OR OTHER DEVICE OR VEHICLE.
11. DO NOT USE LADDER, SCAFFOLDING, OR OTHER
DEVICES TO INCREASE SIZE OR WORKING HEIGHT
OF PLATFORM.
12. DO NOT ENTER OR EXIT PLATFORM WHILE IN MOTION.
13. DO NOT RECHARGE BATTERIES NEAR
SPARKS OR OPEN FLAME, BATTERIES EMIT
HIGHLY EXPLOSIVE HYDROGEN GAS.
14. DO NOT PERFORM SERVICE ON THE MACHINE WITHOUT
PROPERLY SUPPORTING ELEVATING ASSEMBLY.
15. DO NOT ATTACH OVERHANGING LOADS OR
INCREASE PLATFORM SIZE.
91846
10 10 10
13 13 13
DISTANCE FROM GROUND TO LADDER WILL VARY WITH GROUND VARIATIONS.
CHECK DISTANCE BEFORE LEAVING PLATFORM.
18 18 18
ANSI Speed Level™ RT Models: Sheet 1 of 4
RT MODELS - ANSI
YOU MUST NOT OPERATE
TIP-OVER HAZARDS
THIS MACHINE:
UNLESS YOU HAVE BEEN AUTHORIZED TO
USE AND TRAINED IN THE SAFE OPERATION
OF THIS MACHINE.
TRAINING INCLUDES COMPLETE KNOWLEDGE OF
THE SAFETY AND OPERATION INSTRUCTIONS
DO NOT DRIVE NEAR DROP-OFFS,
CONTAINED IN THE MANUFACTURERS MANUAL,
HOLES, OPEN ELEVATOR SHAFTS,
ANSI MANUAL OF RESPONSIBILITIES, YOUR
AND LOADING DOCKS
EMPLOYERS WORK RULES AND APPLICABLE
GOVERNMENTAL REGULATIONS.
AN UNAUTHORIZED AND UNTRAINED OPERATOR
SUBJECTS THEMSELF AND OTHERS TO
DEATH OR SERIOUS INJURY.
ELECTROCUTION HAZARD
THIS MACHINE IS NOT INSULATED
DO NOT ELEVATE PLATFORM ON
UNEVEN OR SOFT SURFACES
MAINTAIN SAFE CLEARANCE FROM ELECTRICAL
LINES AND APPARATUS. YOU MUST ALLOW FOR
MACHINE SWAY, ROCK OR SAG AND ELECTRICAL DO NOT DRIVE ONTO UNEVEN OR
LINES SWAYING. SOFT SURFACES WHEN ELEVATED
THIS MACHINE DOES NOT PROVIDE PROTECTION
FROM CONTACT WITH OR PROXIMITY TO AN
ELECTRICALLY CHARGED CONDUCTOR.
YOU MUST MAINTAIN A CLEARANCE OF AT
LEAST TEN (10) FEET BETWEEN ANY PART
DO NOT RAISE PLATFORM IN
OF THIS MACHINE OR ITS LOAD AND ANY
WINDY OR GUSTY CONDITIONS
ELECTRICAL LINE OR APPARATUS CARRYING UP
TO 50,000 VOLTS. ONE FOOT OF ADDITIONAL
CLEARANCE IS REQUIRED FOR EVERY
ADDITIONAL 30,000 VOLTS OR LESS.
DEATH OR SERIOUS INJURY DEATH OR SERIOUS INJURY
WILL RESULT FROM CONTACT WILL RESULT FROM IMPROPER
OR INADEQUATE CLEARANCE USE OF THIS EQUIPMENT
11 11 11
CERTIFIED LANYARD
ANCHORAGE POINT
14 14 14
91849
19 19 19
AUTO LEVEL
20 20 20
HOLD SWITCH UNTIL
LEVELING IS COMPLETE
MANUAL LEVEL
HOLD SWITCH IN
DESIRED DIRECTION
January 2019
91845
8605
Front to Rear
Side to Side
91843
Decals
