Gp400 Control Module Setup - Mec Speed Level Series Service & Parts Manual

Secton 6 - Electrcal System
Location
• The GP400 Control Module processor is located
in the lower control box.
• The GP400 Matrix Module is located in the upper
control box.
Diagnostic information can be found in Section 9 or 10
for Troubleshooting. Wiring information can be found in
Section 11: Schematics.
Page 57

GP400 Control Module Setup

Speed Level Seres - Servce & Parts Manual
Upper Controls
GP400
Matrix Module
ART_3156
January 2019
Lower Controls
GP400
Control Module
Terminal
Block
Module
Diagnostic LED
