Mec Speed Level Series Service & Parts Manual page 235

Secton 14 - Axles
Item Part Number
91166
91168
1 91578
91580
91581
91165
91167
2 91577
91579
91581
Incl 91180
3 50165
4 16349
5 19168
6 50010
7 50001
8 50051
9 40258
10 50043
11 50253
12 50151
13 14773
14 HDW9037
15 50170
91319
94863
16
9781
91138
17 50659
18 50646
19 50647
20 50008
21 50044
22 91585
23 HDW6676
Page 228
Wheel/Tire Assy, LH - 10 PLY - Pneumatic (ANSI Standard)
Wheel/Tire Assy, LH - 10 PLY - Foam (ANSI Option) (CE Standard)
Wheel/Tire Assy, LH - Non-Marking Pneumatic (ANSI Option)
Wheel/Tire Assy, LH - Non-Marking Foam (ANSI, CE Option)
Wheel/Tire Assy, LH - Turf Pneumatic (ANSI Option)
Wheel/Tire Assy, RH - 10 PLY - Pneumatic (ANSI Standard)
Wheel/Tire Assy, RH - 10 PLY - Foam (ANSI Option) (CE Standard)
Wheel/Tire Assy, RH - Non-Marking Pneumatic (ANSI Option)
Wheel/Tire Assy, RH - Non-Marking Foam (ANSI, CE Option)
Wheel/Tire Assy, RH - Turf Pneumatic (ANSI Option)
Wheel (Service)
Nut, Lug, ½" - 20, GR 5
Bottom Hose Cover
Top Hose Cover
Screw, M8 x 25
Washer, Lock, M8
Nut, M16
Mount, Motor, Rear Axle, Machined
Bolt, M16 x 40
Washer, Lock, 5/8
Screw, 5/8"-11, 2.25" LG, GR 5
Hub
Nut, Castle, M42 X 3 (Service)
Pin, Cotter, .250 DIA. X 3" LG
Wheel Motor, Hyd W/Brake
Hyd Drive Motors 160CC
3084RT - From Serial #11800423
Seal Kit
Brake Kit
Fitting, MB-MJ-12-8
Fitting, MB-MJL-4-4
Fitting, MB-MJ90L-4-4
Washer, Lock, M16
Bolt, M16 x 60 G10.9
Valve Assembly With Coil (XX84ES Models Only)
3084ES - From Serial #11700100
Wheel Stud 1/2-20 x 1 3/4 LG
Incl - Included with Assembly
Speed Level Seres - Servce & Parts Manual
Description
January 2019
