Ez-Cal Adjustment - Mec Speed Level Series Service & Parts Manual

Secton 8 - Troubleshootng - 3084RT Models
Refer to "Using the EZ-Cal Scan Tool" on page 91.
Adjustments possible in Access Level 1 Only.
Before changing personalities, ensure that the correct customer and model have been selected in the
SETUPS menu. Any changes to settings will be lost when the model or customer is changed.
To reach ADJUSTMENTS, first access Level 1, then press --> for ADJUSTMENTS. Press Enter, then
press --> to scroll through the sub-menus.
Once the desired sub-menu is found, press Enter again, then --> to scroll through the personalities.
Press the Up or Down arrows to change the personality. Press ESC to go back one or more levels to
reach other sub-menus.
Operation ID
5A-1
5A-2
5A
5A-3
DRIVE
5A-4
(PLATFORM
5A-5
STOWED)
5A-6
5A-7
POSITRACK 5A-8
5A-8a
Sub Menu
5A-8b
5B-1
5B-2
5B
5B-3
DRIVE
5B-4
ELEVATED
5B-5
5B-6
5C-1
5C-2
5C-3
5C
5C-4
LIFT
5C-5
5C-6
5C-7
ARMGUARD (CE) 5C-8
5C-8a
Sub Menu
5C-8b
5D-1
5D-2
5D
5D-3
STEER
5D-4
5D-5
5E - DECK 5E-
Page 97

EZ-Cal Adjustment

Personality
FWD Min
FWD Max
REV Min
REV Max
ACCEL
DECEL
MAX Height
Positrack
AUTO below
AUTO
FWD Min
FWD Max
REV Min
REV Max
ACCEL
DECEL
UP Min
UP Max
DOWN Min
DOWN Max
ACCEL
DECEL
MAX Height ANSI: 101%
Armguard
Armguard Time
Armguard @ Height
Speed
Drive Compensation
Drive Comp Elevated
ACCEL
DECEL
Not Used
Speed Level Seres - Servce & Parts Manual
Factory Setting
33% Slowest speed possible
100% Maximum speed potential
31% Slowest speed possible
100% Maximum speed potential
1.8 sec Ramp-up time to maximum
1.6 sec Ramp-down time to stop
101% Maximum drivable height
- Sub category, press ENTER to access
0% Not Used
Not Used Not Used
33% Slowest speed possible
46% Maximum speed potential
31% Slowest speed possible
49% Maximum speed potential
5.0 sec Ramp-up time to maximum
5.0 sec Ramp-down time to stop
5% Slowest speed possible
52% Maximum speed potential
0% (not used) Gravity down (not used)
0% (not used) Gravity down (not used)
1.2 sec Ramp-up time to maximum
0.5 sec Ramp-down time to stop
CE: 98% Maximum height potential
- Sub category, press ENTER to access
0.0 sec CE Option Only
101% CE Option Only
0% Maximum speed potential
0% Adds additional to drive speed
0% Adds additional to drive speed elevated
0.2 sec Ramp-up time to maximum
0.2 sec Ramp-down time to stop
Not Used Power-out deck (not used)
January 2019
Explanation
