Mec 1330SE Service & Parts Manual

Hide thumbs Also See for 1330SE:

Advertisement

Quick Links

Download this manual
Service & Parts Manual
1330SE
ILLUSTRATION No.
ART_4907
Meets requirements of ANSI A92.20-2020 and CSA B354.6-2019.
Part # 95834
October 2024
Serial Number Range 16307700 - Up

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1330SE and is the answer not in the manual?

Questions and answers

Related Manuals for Mec 1330SE

Summary of Contents for Mec 1330SE

  • Page 1 Service & Parts Manual 1330SE ILLUSTRATION No. ART_4907 Meets requirements of ANSI A92.20-2020 and CSA B354.6-2019. Part # 95834 October 2024 Serial Number Range 16307700 - Up...

  • Page 2: Revision History

    Revision History Date Reason for Update November 2021 New Release MEC Aerial Work Platforms 1401 S. Madera Avenue, Kerman, CA 93630 USA Toll Free: 1-877-632-5438 Phone: 1-559-842-1500 Fax: 1-559-842-1520 info@MECawp.com www.MECawp.com Page i 1330SE - Service & Parts Manual - 95834...

  • Page 3: Table Of Contents

    � � � � � � � 33 Electrical Schematic � � � � � � � � � � � � � � � � � � � 34 Page ii 1330SE - Service & Parts Manual - 95834...
  • Page 4 Section 19 - Decals . . 86 Decals � � � � � � � � � � � � � � � � � � � � � � � 86 Page iii 1330SE - Service & Parts Manual - 95834...

  • Page 5: Chapter 1 - Service

    All parts represented here are manufactured and supplied in accordance with MEC quality standards. We recommend that you use genuine MEC parts to ensure proper operation and reliable performance. To obtain maximum benefits from your MEC Aerial Work Platforms, always follow the proper operating and maintenance procedures.

  • Page 6: Section 1 - Mec Operator Policy

    Any procedures not found within this manual must be evaluated by the individual to assure oneself that they are “proper and safe.” Your MEC Aerial Work Platform has been designed, built, and tested to provide many years of safe, dependable service. Only trained, authorized personnel should be allowed to operate or service the machine.

  • Page 7: Section 2 - Safety Symbols & General Safety Tips

    October 2024 Safety Symbols & General Safety Tips Safety Symbols & General Safety Tips MEC manuals and decals use symbols, colors and signal words to help you recognize important safety, operation and maintenance information. ART_6091 RED and the word DANGER – Indicates an imminently hazardous DANGER situation which, if not avoided, will result in death or serious injury.

  • Page 8: Section 3 - Torque Specifications

    Torque values apply to fasteners as received from the supplier, dry or when lubricated with normal engine oil. If special graphite grease, molydisulphide grease, or other extreme pressure lubricants are used, these torque values do not apply. Page 4 1330SE - Service & Parts Manual - 95834...

  • Page 9: Bolt Torque Specification - Metric Standard

    Torque values apply to fasteners as received from the supplier, dry or when lubricated with normal engine oil. If special graphite grease, molydisulphide grease, or other extreme pressure lubricants are used, these torque values do not apply. Page 5 1330SE - Service & Parts Manual - 95834...

  • Page 10: Hydraulic Components Torque Table

    85 - 90 115 - 122 950 - 1050 107 - 119 130 - 140 176 - 190 130 - 140 176 - 190 1300 - 1368 147 - 155 Page 6 1330SE - Service & Parts Manual - 95834...

  • Page 11: Section 4 - Specifications

    Chassis Inclination 1.5 Side , 3.0 Inline Meets requirements of ANSI A92.20-2020 and CSA B354.6-2019. *Working Height adds 6 feet (2 meters) to platform height. **Weight may increase with certain options. Page 7 1330SE - Service & Parts Manual - 95834...

  • Page 12: Section 5 - Maintenance Lock

    2. Rotate the Maintenance Lock away from the machine and let it hang down. 3. Lower the platform until the Maintenance Lock rests securely on the link. Keep clear of the Maintenance Lock when lowering the platform. Maintenance Lock ART_4995 Page 8 1330SE - Service & Parts Manual - 95834...

  • Page 13: Section 6 - Machine Systems

    IMMEDIATELY REPORT TO YOUR SUPERVISOR ANY DEFECT OR MALFUNCTION. ANY DEFECT SHALL BE REPAIRED PRIOR TO CONTINUED USE OF THE AERIAL WORK PLATFORM. INSPECTION AND MAINTENANCE SHOULD BE PERFORMED BY QUALIFIED PERSONNEL FAMILIAR WITH THE EQUIPMENT. Page 9 1330SE - Service & Parts Manual - 95834...

  • Page 14: Section 7 - Primary Machine Components

    14) Scissor 15) Safety Arm 16) Lanyard Anchorage Point 17) Platform Extension 18) Manual Storage Container 19) Hydraulic Pump 20) Batteries 21) Motor Controller ILLUSTRATION No. 22) Forklift Pockets/Tie-Down Points ART_5229 Page 10 1330SE - Service & Parts Manual - 95834...

  • Page 15: Section 8 - Emergency Systems And Procedures

    The Emergency Lowering System is used to lower the platform in case of power failure. To lower the platform, pull the Emergency Lowering Knob, located near the Emergency Base Control panel. Lowering Knob ILLUSTRATION No. ART_6212 Page 11 1330SE - Service & Parts Manual - 95834...

  • Page 16: Section 9 - Transport And Lifting Instructions

    Push in the Emergency Stop button or turn the Key Switch to the Off position to reset the brakes. ART_6091 BE SURE THAT THE BRAKES ARE ENGAGED BEFORE REMOVING THE WARNING WHEEL CHOCKS. Page 12 1330SE - Service & Parts Manual - 95834...

  • Page 17: Lift And Support The Machine

    5. Lower the machine to rest on the jack stands and inspect for stability. To Lower the Machine 1. Raise machine slightly and remove jack stands. 2. Lower the machine and remove the jack. 3. Remove chocks. Page 13 1330SE - Service & Parts Manual - 95834...

  • Page 18: Section 10 - Maintenance Maintenance

    Use only recommended lubricants. Improper lubricants or incompatible lubricants may cause as much damage as no lubrication. Watch for makeshift “fixes” which can jeopardize safety as well as lead to more costly repair. Page 14 1330SE - Service & Parts Manual - 95834...
  • Page 19 3. Remove the wheel covers and check each center lock nut for proper torque and presence of cotter pin. Front Back 166.7 ft-Ibs (226 Nm) Locknut 100ft-Ibs (135 Nm) Castle Nut Torque, Dry Castle Nut Torque, Lubricated 125.4 ft-Ibs (170 Nm) Page 15 1330SE - Service & Parts Manual - 95834...

  • Page 20: Pre-Start Inspection Checklist

    Be sure that the chassis trays are closed and latched and the batteries are properly connected. NEVER perform work or inspection on the machine with the platform ART_6091 elevated without first blocking the scissor assembly with the WARNING Maintenance Lock. See page 8 for instructions. Page 16 1330SE - Service & Parts Manual - 95834...

  • Page 21: Frequent Inspection Checklist

    7. Inspect the battery charger plug and pigtail for damage or excessive insulation wear. Replace as required. 8. Connect the battery charger to a properly grounded 110-230V (50-60 Hz) single phase AC Page 17 1330SE - Service & Parts Manual - 95834...
  • Page 22 All wire harness connectors Level sensor 9. Raise the platform and return the safety arm to the stowed position. 10. Lower the platform to the stowed position and turn the machine off. Page 18 1330SE - Service & Parts Manual - 95834...
  • Page 23 2. Turn the key switch to platform control. 3. Check the platform up/down function from the ground controls. • Result: The machine functions should not operate. 4. Turn the key switch to ground control. Page 19 1330SE - Service & Parts Manual - 95834...
  • Page 24 Drive performance should also be free of hesitation, jerking and unusual noise over the entire proportionally controlled speed range. Perform this procedure with the machine on a firm, level surface that is free of obstructions. Page 20 1330SE - Service & Parts Manual - 95834...
  • Page 25 4. Press the slow speed select button. 5. Choose a point on the machine; i.e., contact patch of a tire, as a visual reference for use when crossing the start and finish lines. Page 21 1330SE - Service & Parts Manual - 95834...
  • Page 26 Note: When checking for positive tank cap venting, air should pass freely through the cap. 3. Using a mild solvent, carefully wash the cap venting system. Dry using low pressure compressed air. Repeat step 2. 4. Install the breather cap onto the hydraulic tank. Page 22 1330SE - Service & Parts Manual - 95834...

  • Page 27: Annual Inspection Checklist

    Extremely dirty conditions may require that the cap be inspected more often. 1. Remove and discard the hydraulic tank breather cap. 2. Install a new cap onto the tank. Page 23 1330SE - Service & Parts Manual - 95834...
  • Page 28 Hydraulic Tank Retaining Fasteners, Dry: 35in-Ibs (4Nm) • Hydraulic Tank Drain Plug, Lubricated: 26in-Ibs (3Nm) • 10. Install the hydraulic power pack into the component tray. Install the fitting and hydraulic hoses Page 24 1330SE - Service & Parts Manual - 95834...
  • Page 29 ART_6091 IF OPERATED WITHOUT OIL. BE CAREFUL NOT TO EMPTY THE WARNING HYDRAULIC TANK WHILE IN THE PROCESS OF FILLING THE HYDRAULIC SYSTEM. DO NOT ALLOW THE PUMP TO CAVITATE. Page 25 1330SE - Service & Parts Manual - 95834...

  • Page 30: Maintenance Inspection Report

    Steering pressure relief, set correctly Fasteners tight Lift pressure relief, set correctly Cover panels secure **Check Platform Overload Sensing operation Welds **For machine equipped with Platform Overload Protection system only Page 26 1330SE - Service & Parts Manual - 95834...

  • Page 31: Section 11 - Control System

    Pothole Switch (each side, inside wheel well) Main Power Switch Drive Motor Battery (under cover) Charger Height Sensor Lower Controls/ Potentiometer (under cover) Drive Motor ILLUSTRATION No. (under cover) ART_5097 Page 27 1330SE - Service & Parts Manual - 95834...

  • Page 32: Upper Controls

    Fault Codes, when present, appear on the LED Indicator at the Upper Controls station and on the LED Screen at the Lower Controls station. Upper Controls LED Indicator ILLUSTRATION No. ART_5592 1330SE Lower Controls LED Indicator Page 28 1330SE - Service & Parts Manual - 95834...

  • Page 33: Error Indicator Readout

    Check the drive motor and wiring for shorts, Motor Controller Output Fault All Models and the drive motor controller and wiring. Motor Controller SRO Fault All Models Replace motor controller Page 29 1330SE - Service & Parts Manual - 95834...
  • Page 34 Right Brake Coil - Brakes about 46 1930SE/Micro to brakes, wiring to drive motors, motor ohms controller and wiring. Check battery voltage, right motor brake All Models and wiring, brake module and wiring, and contactor. Page 30 1330SE - Service & Parts Manual - 95834...
  • Page 35 Check to see if machine is tilted, then check All Models Fault wiring to tilt sensor and the tilt sensor. Indicates that key switch is in base controls. NOT A FAULT CODE All Models Page 31 1330SE - Service & Parts Manual - 95834...

  • Page 36: Section 12 - Schematics

    S te e r C ylinder Steer Valve Steer Relief Lift Valve Main Relief G e a r P um p M o tor F ilter T ank 1330 HYDRAULIC SCHEMATIC ART_5053 Page 32 1330SE - Service & Parts Manual - 95834...

  • Page 37: Hydraulic Unit

    Breather Cap/ Dipstick Hydraulic Reservoir Steer Relief (RV2) Steer Valve (SCV2) Lift Hose Right Steer Hose Left Steer Hose Lift Valve (SCV1) Lift Relief (RV1) Pump Motor 1330 HYDRAULIC UNIT ART_5066 Page 33 1330SE - Service & Parts Manual - 95834...

  • Page 38: Electrical Schematic

    Section 12 - Schematics October 2024 Electrical Schematic ILLUSTRATION No. 1330SE, Micro13-XD Electrical Schematic ART_5823 Page 34 1330SE - Service & Parts Manual - 95834...

  • Page 39: Chapter 2 - Parts

    This Parts sections consists of illustrated parts sections and is designed to provide you, the customer, with illustrations and the list of associated parts needed to properly maintain the MEC self-propelled aerial work platform. When used in conjunction with the Service section in this manual and the Operator’s Manual (provided separately), this manual will assist you in making necessary adjustments...

  • Page 40: Section 13 - Chassis

    Section 13 - Chassis October 2024 Steer Linkage and Wheels Assembly, To Serial #16308570 Steer Linkage and Wheels Assembly, To Serial #16308570 ILLUSTRATION No. Micro13-XD Steer Linkage and Wheels Assembly Art_5627 Page 36 1330SE - Service & Parts Manual - 95834...
  • Page 41 Castle Nut M16 × 1.50 41328 53282 Screw CSCS M08-1.25 × 20 44042 Steer Yoke Weldment 41222 Bearing 41221 Tie Rod 50311 Nut NNYL M10-1.50 Flange 41199 Washer 41202 Bearing Page 37 1330SE - Service & Parts Manual - 95834...

  • Page 42: Steer Linkage And Wheels Assembly, From Serial #16308571

    Section 13 - Chassis October 2024 Steer Linkage and Wheels Assembly, From Serial #16308571 ILLUSTRATION No. Micro13-XD Steer Linkage and Wheels Assembly Art_5627 Page 38 1330SE - Service & Parts Manual - 95834...
  • Page 43 Castle Nut M16 × 1.50 41328 53282 Screw CSCS M08-1.25 × 20 46740 Steer Yoke Weldment 41222 Bearing 41221 Tie Rod 50311 Nut NNYL M10-1.50 Flange 41199 Washer 41202 Bearing Page 39 1330SE - Service & Parts Manual - 95834...

  • Page 44: Drive Wheel Assembly, To Serial #16308570

    Section 13 - Chassis October 2024 Drive Wheel Assembly, To Serial #16308570 ILLUSTRATION No. Micro13-XD Drive Wheel Assembly Art_5628 Page 40 1330SE - Service & Parts Manual - 95834...
  • Page 45 41240 Left Drive Motor Assembly 43752 Left Motor 42515 Reducer 44859 Output Shaft 44033 Brake 44062 Plate (With Platform Power) 42883 Connector, Drive Motor 53318 Screw PHMS M06-1.00 × 12 Page 41 1330SE - Service & Parts Manual - 95834...

  • Page 46: Drive Wheel Assembly, From Serial #16308571

    Section 13 - Chassis October 2024 Drive Wheel Assembly, From Serial #16308571 ILLUSTRATION No. Micro13-XD Drive Wheel Assembly Art_5628 Page 42 1330SE - Service & Parts Manual - 95834...
  • Page 47 Left Drive Motor Assembly 46747 Left Motor 46743 Reducer 46744 Output Shaft 44033 Brake 46745 46748 Plate 53318 Screw PHMS M06-1.00 × 12 41575 Plug 53263 Screw THMS M04-0.70 × 8 Page 43 1330SE - Service & Parts Manual - 95834...

  • Page 48: Pothole Protection Assembly

    Section 13 - Chassis October 2024 Pothole Protection Assembly ILLUSTRATION No. 1330SE / MICRO13-XD Pothole Protection Assembly ART_5824 Page 44 1330SE - Service & Parts Manual - 95834...
  • Page 49 44609 Pothole Guide 41203 Bearing 44610 Seal 41204 Pothole Hole Pusher Pin 44007 Adjusting Washer 2 44008 Adjusting Washer 3 41205 Pothole Hole Pusher Rod 47376 Pivot Pin, Pothole Weld Page 45 1330SE - Service & Parts Manual - 95834...

  • Page 50: Battery Pack Module, To Serial #16308570

    Section 13 - Chassis October 2024 Battery Pack Module, To Serial #16308570 ILLUSTRATION No. Micro13-XD Battery Pack Module Art_5630 Page 46 1330SE - Service & Parts Manual - 95834...
  • Page 51 Glide Track 53225 Screw CSCS M10-1.50 × 30 41337 Bracket 50002 WSHR M10 Standard Flat Washer 53054 WSHR M10 Spring Washer 50127 Screw SHCS M10-1.50 × 30 REF - Reference Page 47 1330SE - Service & Parts Manual - 95834...

  • Page 52: Battery Pack Module, From Serial #16308571

    Section 13 - Chassis October 2024 Battery Pack Module, From Serial #16308571 ILLUSTRATION No. Micro13-XD Battery Pack Module Art_5630 Page 48 1330SE - Service & Parts Manual - 95834...
  • Page 53 Glide Track 53225 Screw CSCS M10-1.50 × 30 41337 Bracket 50002 WSHR M10 Standard Flat Washer 53054 WSHR M10 Spring Washer 50127 Screw SHCS M10-1.50 × 30 REF - Reference Page 49 1330SE - Service & Parts Manual - 95834...

  • Page 54: Hydraulic Power Unit

    Section 13 - Chassis October 2024 Hydraulic Power Unit ILLUSTRATION No. Micro13-XD Hydraulic Power Unit Art_5631 Page 50 1330SE - Service & Parts Manual - 95834...
  • Page 55 41894 Coil (To Serial #16308570) 43810 Coil (From Serial #16308571) 43811 Check Valve 41245 Solenoid Valve Spool 41243 Motor 43812 Pressure Compensation Valve 43813 Relief Valve 42894 Coupler, Motor Pump Page 51 1330SE - Service & Parts Manual - 95834...

  • Page 56: Motor Controller Assembly

    Section 13 - Chassis October 2024 Motor Controller Assembly ILLUSTRATION No. Micro13-XD Motor Controller Assembly Art_5632 Page 52 1330SE - Service & Parts Manual - 95834...
  • Page 57 150A Fuse 41092 Fuse Seat 53355 Screw PHMS M05-0.80 × 14 53038 WSHR M05 Standard Flat Washer 53043 WSHR M05 Spring Washer 53222 Screw PHMS M05-0.80 × 8 41331 DC Contactor Page 53 1330SE - Service & Parts Manual - 95834...

  • Page 58: Ground Control Assembly

    Section 13 - Chassis October 2024 Ground Control Assembly ILLUSTRATION No. Micro13-XD Ground Control Assembly Art_5633 Page 54 1330SE - Service & Parts Manual - 95834...
  • Page 59 Base With 1 NC Contact 43992 Select Switch (To Serial #16308570) 46755 Select Switch (From Serial #16308571) 43993 Select Switch Head 43994 Base With 1 NO Contact 43096 NC Contact Page 55 1330SE - Service & Parts Manual - 95834...

  • Page 60: Chassis And Accessories, To Serial #16308570

    Section 13 - Chassis October 2024 Chassis and Accessories, To Serial #16308570 ILLUSTRATION No. 1330SE / MICRO13-XD Chassis and Accessories ART_5825 Page 56 1330SE - Service & Parts Manual - 95834...
  • Page 61 Screw SHCS M04-0.70 × 12 41198 Switch Cover 50289 Screw HHCS M06-1.00 × 40 42403 Sensor Bracket 50568 Nut NNYL M06-1.00 Flange 41098 Tilt Sensor 53043 WSHR M05 Spring Washer Page 57 1330SE - Service & Parts Manual - 95834...

  • Page 62: Chassis And Accessories, From Serial #16308571

    Section 13 - Chassis October 2024 Chassis and Accessories, From Serial #16308571 ILLUSTRATION No. 1330SE / MICRO13-XD Chassis and Accessories ART_5825 Page 58 1330SE - Service & Parts Manual - 95834...
  • Page 63 Screw SHCS M04-0.70 × 12 41198 Switch Cover 50289 Screw HHCS M06-1.00 × 40 42403 Sensor Bracket 50568 Nut NNYL M06-1.00 Flange 41098 Tilt Sensor 53043 WSHR M05 Spring Washer Page 59 1330SE - Service & Parts Manual - 95834...

  • Page 64: Section 14 - Scissor

    Section 14 - Scissor October 2024 Scissor Assembly Scissor Assembly ILLUSTRATION No. Micro13-XD Scissor Assembly Art_5635 Page 60 1330SE - Service & Parts Manual - 95834...
  • Page 65 Screw HHCS M06-1.00 × 20 Serrated Flange 42446 Bearing 41343 Outer Arm 2 (To Serial #16308570) 46762 Outer Arm 2 (From Serial #16308571) 41114 Block 42457 41354 Washer 42437 Circlips 41256 Platform Slider Page 61 1330SE - Service & Parts Manual - 95834...

  • Page 66: Section 15 - Platform

    Section 15 - Platform October 2024 Main Platform Assembly Main Platform Assembly ILLUSTRATION No. 1330SE / MICRO13-XD Main Platform Assembly ART_5826 Page 62 1330SE - Service & Parts Manual - 95834...
  • Page 67 Sheath 42462 Washer 53359 Screw HHCS M08-1.25 × 55 Flange 44584 Entry Gate 53360 Screw HHCS M06-1.00 × 45 Flange 41277 Spring 41278 Latch Handle 50568 Nut NNYL M06-1.00 Flange Page 63 1330SE - Service & Parts Manual - 95834...

  • Page 68: Platform Extension Assembly

    Section 15 - Platform October 2024 Platform Extension Assembly ILLUSTRATION No. 1330SE / MICRO13-XD Platform Extension Assembly ART_5827 Page 64 1330SE - Service & Parts Manual - 95834...
  • Page 69 Slide Pad 41360 Roller Bracket 53280 Screw CSCS M08-1.25 × 55 44812 Right Extension Rail 44800 Left Extension Rail 41120 Bumper 53378 Screw PHMS M05-0.80 × 12 REF - Reference Page 65 1330SE - Service & Parts Manual - 95834...

  • Page 70: Platform Control Assembly

    Section 15 - Platform October 2024 Platform Control Assembly ILLUSTRATION No. Micro13-XD Platform Control Assembly Art_5638 Page 66 1330SE - Service & Parts Manual - 95834...
  • Page 71 Platform Control Box Assembly (From Serial #16308571) (Refer to page 68) 42499 Platform Control Box Mount Bracket 50048 NNYL M08 × 1.25 42501 Handle 42500 Locating Plate 53231 PHMS M06-1.00 × 16 53248 CARB M08-1.25 × 45 REF - Reference Page 67 1330SE - Service & Parts Manual - 95834...

  • Page 72: Platform Control Box Assembly

    Section 15 - Platform October 2024 Platform Control Box Assembly ILLUSTRATION No. Micro13-XD Platform Control Box Assembly Art_5639 Page 68 1330SE - Service & Parts Manual - 95834...
  • Page 73 41155 Button 41157 Emergency Stop Switch 43632 Red Mushroom Head 43633 Base With 1 NC Contact 42915 Decal, Emergency Stop Panel 43634 Enclosure 43635 Cover Bottom 41271 Replacement Connector, Gray Page 69 1330SE - Service & Parts Manual - 95834...

  • Page 74: Platform Locking Device Assembly

    Section 15 - Platform October 2024 Platform Locking Device Assembly ILLUSTRATION No. Micro13-XD Platform Locking Device Assembly Art_5640 Page 70 1330SE - Service & Parts Manual - 95834...
  • Page 75 Nut NNYL M10 × 1.50 50002 WSHR M10 Standard Flat Washer 41143 Foot Pedal 41144 Lock Pin Housing 41145 Spring 41146 Lock Pin 44767 Bracket 50020 Screw HHCS M10-1.50 × 50 Page 71 1330SE - Service & Parts Manual - 95834...

  • Page 76: Section 16 - Hydraulics

    Section 16 - Hydraulics October 2024 Lift Cylinder Assembly Lift Cylinder Assembly ILLUSTRATION No. 1330SE / MICRO13-XD Lift Cylinder Assembly ART_5828 Page 72 1330SE - Service & Parts Manual - 95834...
  • Page 77 Plate 41292 Support 53179 Screw HHCS M05-0.80 × 20 44004 Cable Connector 53362 Nut NHEX 1/2-20 UNF 41295 Seal Kit 43369 Check Valve 42821 Plug Orifice 43370 42553 Hose 41413 Page 73 1330SE - Service & Parts Manual - 95834...

  • Page 78: Hydraulic Hoses And Fittings

    Section 16 - Hydraulics October 2024 Hydraulic Hoses and Fittings Steer Cylinder Hose Assembly Adapter Hydraulic Power Unit Union ILLUSTRATION No. 1330SE / MICRO13-XD Hydraulic Hoses and Fittings ART_5832 Page 74 1330SE - Service & Parts Manual - 95834...
  • Page 79 Item Part Number Description Qty. 41296 Straight Fitting 44860 Straight Fitting 41298 Straight Fitting 43638 Straight Fitting 43639 Elbow 42480 Plug 42477 Hose Assembly 44861 Hose Assembly 44030 Hose Assembly Page 75 1330SE - Service & Parts Manual - 95834...

  • Page 80: Section 17 - Electrical System

    Sensor Limit Horn Switch Limit Coil Switch Ground Control Right Motor Left Motor Assembly Charger Power Fuse Motor Contactor Switch Assembly Controller Battery Motor ILLUSTRATION No. Micro13-XD Electrical Harness Art_5644 Page 76 1330SE - Service & Parts Manual - 95834...
  • Page 81 150A Fuse Assembly (Refer to page 52) Power Switch (Refer to page 54) Battery (Refer to page 46) Charger (Refer to page 46) 41922 Harness, Platform Control Box REF - Reference Page 77 1330SE - Service & Parts Manual - 95834...

  • Page 82: Electrical Harness, From Serial #16308571

    Switch Limit Switch Hydraulic Power Unit Horn Ground Control Right Motor Left Motor Assembly Charger Power Fuse Motor Contactor Switch Assembly Controller Battery Motor ILLUSTRATION No. Micro13-XD Electrical Harness Art_5644 Page 78 1330SE - Service & Parts Manual - 95834...
  • Page 83 Hydraulic Power Unit 41075 Horn 43752 Left Motor 43751 Right Motor 41610 Motor Controller 41243 Motor 41331 DC Contactor 44031 150A Fuse 42071 Power Switch 41330 Battery 42904 Charger REF - Reference Page 79 1330SE - Service & Parts Manual - 95834...

  • Page 84: Power To Platform

    Section 17 - Electrical System October 2024 Power to Platform ILLUSTRATION No. 1330SE / MICRO13-XD Power to Platform ART_5829 Page 80 1330SE - Service & Parts Manual - 95834...
  • Page 85 Part Number Description Qty. 44034 Wire Cable, Platform AC Power 91597 Outlet Box 91598 Outlet Cover Outlet, 15A 120V GFCI 92007 53040 Screw, HHSM #8 x 0.5 92008 Strain Relief Page 81 1330SE - Service & Parts Manual - 95834...

  • Page 86: Section 18 - Options

    PLATFORM CABLE HERE: BROWN = LINE BLUE = NEUTRAL = GROUND CONNECT TO BATTERY GROUND. CONNECTS TO INVERTER RELAY TERMINAL 87 CONTROL SIDE ILLUSTRATION No. 1330SE / MICRO13-XD 900W Inverter ART_5830 Page 82 1330SE - Service & Parts Manual - 95834...
  • Page 87 Power Inverter, 900W 24V DC To AC 94359 91544 Plug, Male 3 Prong 15 Amp 53097 FHSC M5-0.8X12MM Inverter Relay Assembly 41967 50330 THMS #10-32X01.00 ZP Inverter Option: Ground Cable Ground Cable Jumper 43754 Page 83 1330SE - Service & Parts Manual - 95834...

  • Page 88: Leak Containment System

    Section 18 - Options October 2024 Leak Containment System GOES HERE; INSIDE OF CYLINDER GUARD ADD 14 TO BOLTS ILLUSTRATION No. 1330SE / MICRO13-XD Leak Containment System ART_5831 Page 84 1330SE - Service & Parts Manual - 95834...
  • Page 89 SHCS M6 X 10 Black Oxide Ultra Low Profile 53370 94866 Leak Containment System, Long Decal 94867 Leak Containment System, Small Decal 95048 Magnet 30LB (Max Pull Force) 95082 Disc Magnet 44LB A0005 Loctite 565 REF - Reference Page 85 1330SE - Service & Parts Manual - 95834...

  • Page 90: Section 19 - Decals

    Section 19 - Decals October 2024 Decals Decals *DECALS HIDDEN BY STEP LADDER PLATFORM EXTENDED CONTROL MODULE *On both sides Page 86 1330SE - Service & Parts Manual - 95834...
  • Page 91 Qty. - 1 94528 Qty. - 1 41640 Qty. - 1 91850 Qty. - 2 43879 Qty. - 1 41632 Qty. - 1 94866 Qty. - 2 94867 Qty. - 1 Page 87 1330SE - Service & Parts Manual - 95834...
  • Page 92 October 2024 Notes Page 88 1330SE - Service & Parts Manual - 95834...
  • Page 93 October 2024 Notes Page 89 1330SE - Service & Parts Manual - 95834...
  • Page 94 MEC Parts Order Form Phone: 559-842-1523 Fax: 559-400-6723 Email: Parts@mecawp.com Please Fill Out Completely: Date: Ordered By: Account: Your Fax No.: Bill to: Ship to: Purchase Order Number Ship VIA ** All orders MUST have a Purchase Order Number **Fed Ex shipments require Fed Ex account number...
  • Page 95 MEC Aerial Platform Sales Corp. and is found upon inspection by MEC Aerial Platform Sales Corp. to be defective in material and/or workmanship. MEC Aerial Platform Sales Corp. shall not be liable for any consequential, incidental or contingent damages whatsoever.
  • Page 96 MEC Aerial Work Platforms 1401 S. Madera Avenue, Kerman, CA 93630 USA Toll Free: 1-877-632-5438 Phone: 1-559-842-1500 Fax: 1-559-842-1520 info@MECawp.com www.MECawp.com...
