Mec Speed Level Series Service & Parts Manual page 141

Secton 9 - Troubleshootng - 3084ES Models
Operation ID
5F-1
5F-2
5F-3
5F
5F-4
OUTRIGGERS
5F-5
Called "Outriggers"
5F-6
on the EZ-Cal,
5F-7
these personalities
control Speed-
5F-8
Level functions
5F-9
5F-10
5F-11
5G-1
5G 5G-2
GROUND MODE
5G-3
5G-4
Lower Control
Operations 5G-5
5G-6
5H-1
5H-2
5H 5H-3
TILT
5H-4
5H-5
5H-5A
5H-5
5H-5B
Sub Menu
5H-5C
5I-1
5I
OVERLOAD
5I-2
5I-3
ANSI: values = 0
5I-4
5I-5
CE: values apply
5I-6
5I-7
5I-8
5I-8a
5I-8
Sub Menu
5I-1b
5J-1
5J
5J-2
ALARMS
5J-3
5K-1
5K-2
5K-3
5K-4
5K
HEIGHTS
5K-5
5K-6
5K-7
5K-8
Page 134
Personality Factory Setting
Outriggers 2 = drive i lock
Extend
Level
Retract
Debounce
Initial
Tilt filter
X Tilt target 0.2 deg
Y Tilt target 0.2 deg
Tilt Slack 0.3 deg
Not Used Not Used
UP
DOWN
OUT
IN
ACCEL 1.0 sec
DECEL 1.0 sec
X Trip 3.0 degrees
Y Trip 3.0 degrees
Delay Trip 2.0 sec
Delay Clear 0.5 sec
Tilt 2
@ Height 101%
X Trip 2 1.5 sec
Y Trip 2 1.5 sec
Trip @ ANSI: 0%
Lamp @ ANSI: 0%
Alarm @ ANSI: 0%
@ Height ANSI: 0%
Safe Down ANSI: 0%
Delay Trip 1.5 sec
Delay Clear 1.5 sec
Overload 2
Height 0%
Scale 100%
Drive: Yes/No
Lift 2 = Down
Tilt 1 = When Elevated
Elevation @
Maximum Drive 101%
Maximum Lift ANSI: 101%
Armguard 101%
Overload ANSI: 0%
Safe Down ANSI: 0%
Overload # 2
Tilt # 2 ANSI: 0%
Speed Level Seres - Servce & Parts Manual
Outrigger program controls level operation
50% Maximum speed potential
35% Extend speed after all legs touch down
55% Maximum speed potential
0.35 Compensates for switch bounce
0.5 Minimum level operating time
6 Compensates for tilt sensor free movement
Target level stops movement - side/side
Target level stops movement - fore/aft
Variance to tilt target
Not Used
65% Maximum speed potential
0% Gravity down (not used)
0% Power deck operation (not used)
0% Power deck operation (not used)
Ramp-up time to maximum
Ramp-down drive output
Angle tilt sensor signals Out Of Level
Angle tilt sensor signals Out Of Level
Time delay between Tip and Signal
Time delay between Tip and Signal OFF
Second tilt setting used for increased stability.
-
Press ENTER to access
Point where lesser tilt angle used
Secondary tilt angle - see 5H-5
Secondary tilt angle - see 5H-5
CE: 110% % of weight over maximum to trigger overload
CE: 0% % of weight over maximum to trigger lamp
CE: 0% % of weight over maximum to trigger alarm
CE: 8% % of elevation load sense starts monitoring weight
CE: 12% % of elevation lift-down still operates in overload
Delay before overload trip
Delay before overload clear
- Sub category - press ENTER to access
0% % of height for secondary overload valve
% of reduced overload valve
No 1 = FWD
1 = UP
1 = When Elevated
15% Point at which machine enters elevated mode
Maximum drivable height
CE: 98% Maximum elevated height potential
Stops descent for 5 sec
CE: 12% % of elevation load sense starts monitoring weight
CE: 18% % of elevation lift-down still operates in overload
0% Not Used
CE: 0% Reduced degree of tilt at % elevation
January 2019
Explanation
2 = REV 3 = Both 4 = All Motion
2 = DOWN 3 = Both 4 = All Motion
2 = Always
