Mec Speed Level Series Service & Parts Manual page 184

Secton 10 - Schematcs
3084ES - Upper Controls Electric Schematic
SCHEMATIC
Model: / Serial #
3084ES | 11800025- UP
Upper Controls
GP400: 21 510 411
Reference Art #: none Publication Art #:
J15
TO: BASE
MAST
CAN TILT MODULE
CAN BUS H
CAN BUS L
GND
12V INPUT
CAN BUS H
CAN BUS L
MATRIX MODULE
P1 12V INPUT POWER-UP
P2
P4
ROLL LEFT & AUTO LEVEL
PITCH & ROLL COMMON
P3
LEVEL INDICATOR LAMP
OVERLOAD LAMP (CE)
Page 177
3084ES
ART_3287
J16
BLK
BARE
RED
GP400
21 510 411
515
P1-1
not used P1-2
BLK
CAN BUS H P1-3
BARE
GROUND P1-4
not used P1-5
CLEAR
CAN BUS L P1-6
BLK
FORWARD / DOWN P2-1
BLK
REVERSE / UP P2-2
GRN
STEER LEFT P2-3
YEL
STEER RIGHT P2-4
RED
ENABLE BAR P2-5
BLK
POTENTIOMETER P2-6
not used
P2-7
not used P2-8
not used P2-9
WHT
POTENTIOMETER P2-10
BLK
POTENTIOMETER P2-11
BLK
SWITCH SUPPLY P2-12
420
SWITCH SUPPLY
P3-1
421
SWITCH SUPPLY P3-2
not used P3-3
423
DRIVE P3-4
422
LIFT P3-5
CHOKE / GLOW P3-6
not used P3-7
not used P3-8
UP SWITCH P3-9
428
ROLL RIGHT P3-10
429
P3-11
438
P3-12
P4-1
not used
not used P4-2
not used P4-3
417
P4-4
425
ALARM (CE) P4-5
not used P4-6
430
P4-7
P4-8
not used
not used P4-9
Speed Level Seres - Servce & Parts Manual
B–
BLU
HORN
YEL
(option)
B+
J17
415 BRN
BRN P31-1
73 YEL
BLU P31-2
515 ORG
ORG P31-3
BLK
BLK P31-4
BARE P31-5
BARE
RED P31-6 RED
OFF/RUN
E-STOP
ENABLE
POT
LIFT/DRIVE
PITCH UP
PITCH DOWN
ROLL RIGHT
ROLL LEFT
TILT LAMP
January 2019
PLATFORM UNDERSIDE
CONTROL BOX
C D E F G H
J18
CONNECTOR
YEL
HORN
415
(option)
73
REV/UP
LEFT
RIGHT
JOYSTICK
HI SPEED
448
449
HI TORQUE
AUTO LEVEL
OVERLOAD ALARM
OVERLOAD LAMP
(CE only)
(CE only)
UPPER CONTROLS
FWD/DOWN
515
