Lower Controls - 3084Rt Dual Fuel/DEsel - Mec Speed Level Series Service & Parts Manual

Secton 6 - Electrcal System
Lower Controls - 3084RT Dual Fuel/Diesel
Raise
2
(Green)
Lower
3
(Green)
Battery
11
Disconnect
Keyswitch
1
Fuel Select Switch
(Dual Fuel Only)
ART_3091
Control
Selector Switch (Key Can Be
1
Removed In Any Position)
2 Raise Button
3 Lower Button
4 Emergency Stop Switch
5 Hour Meter
6 Start Button
7 Choke/glow
8 Start Delay Light
9 Circuit Breaker
10 Emergency Lowering Switch
11 Battery Disconnect
Fuel Selector
12
(Dual Fuel Only)
Page 48
Emergency Stop
4
10
12
Emergency
Lowering
Platform Select to operate from the platform control panel.
Base Select to operate from the base control panel.
Off Select to stop operation from either control panel.
Press and hold to elevate the platform. Release to stop elevation. Throttle
activation is automatic.
Press and hold to lower the platform. Release to stop lowering.
Press to stop all machine functions.
Turn clockwise to reset.
Indicates total elapsed time of machine operation.
Press to start engine. Release when engine starts.
Operate when starting in cold start conditions.
Prevents over-cranking of engine. When lit, starter is disabled. After
approximately 35 seconds the light
will go out and starter will operate.
Trips when there is excessive electrical load. Push to reset.
Push and hold the toggle switch Down to fully lower the platform.
Battery power supply. Turn OFF and padlock to secure machine from
unauthorized use.
Turn switch to select Gasoline or Propane.
Speed Level Seres - Servce & Parts Manual
Hour Meter
5
Description
January 2019
Start Delay
8
7
Choke (Dual Fuel)
Glow (Diesel)
6 Start
9 Circuit Breaker
