Lower Controls - 3084Es ElectrC - Mec Speed Level Series Service & Parts Manual

Secton 6 - Electrcal System
Raise
2
(Green)
Lower
3
(Green)
Battery
8
Disconnect
Keyswitch
1
ART_3245
Control
Selector Switch (Key
1 Can Be Removed In
Any Position)
2 Raise Button
3 Lower Button
Emergency
4
Stop Switch
5 Hour Meter
6 Charge Indicator
7 Circuit Breaker
8 Battery Disconnect
Emergency
9
Lowering Switch
Page 49
Lower Controls - 3084ES Electric
Emergency Stop
4
Platform Select to operate from the platform control panel.
Base Select to operate from the base control panel.
Off Select to stop operation from either control panel.
Press and hold to elevate the platform. Release to stop elevation. Throttle
activation is automatic.
Press and hold to lower the platform. Release to stop lowering.
Press to stop all machine functions.
Turn clockwise to reset.
Indicates total elapsed time of machine operation.
Indicates state of battery charge.
Trips when there is excessive electrical load. Push to reset.
Battery power supply. Turn OFF and padlock to secure machine from unauthorized
use.
Push and hold the toggle switch Down to fully lower the platform.
Speed Level Seres - Servce & Parts Manual
Hour Meter
5
Description
January 2019
Charge Indicator
6
Emergency
9
Lowering
Circuit
7
Breaker
