Ez-Cal Setup - Mec Speed Level Series Service & Parts Manual

Secton 9 - Troubleshootng - 3084ES Models
Refer to "EZ-Cal Scan Tool" on page 127.
Operation ID
6A-1
6A
CHANGE
6A-2
DEFAULTS
6B-1
6D
6B-2
TILT SETUPS
6B-3
6B-4
6C-1
6C-2
6C
6C-3
HEIGHT SETUP
6C-4
6C-5
6C-6
6D 6D-1
LOAD SETUPS
6D-2
(EUROPEAN
6D-3
OPTION ONLY)
6E-1
6E-2
6E
INTERLOCKS 6E-3
6E-4
6E-5
Page 135

EZ-Cal Setup

Personality Factory Setting
Customer 5=xx84ES
3 = 3084ES ANSI
Model Select
4 = 3084ES CE
Calibrate Level? Y = ENTER
WARNING! Refer to Tilt Sensor Calibration instructions before attempting calibration
Tilt Shutdown 0 = Never
Elev Tilt Shutdown 1 = Lift & Drive
Axle Tilt
Elevation @
Calibrate Height Start Calibration
Min Lift
Samples
Tilt Correction
Slow Down
Calibrate Load Start Calibration
Faulty Load
Dynamic Scale
Trigger Only
Trigger Wait
Function hold
Throttle Delay
Starter Delay
Speed Level Seres - Servce & Parts Manual
Choose basic model and power source
Choose model and certification
N = ESC Follow instructions in Section 7 - Level Sensor Calibration
Function shutdown tilted when platform stowed
Function shutdown tilted when platform elevated
3.0 deg Oscillating axle maximum interlock angle
% of maximum height when system goes into elevated
15%
mode
See Section 7 for calibration of Height Sensor
1.0 sec Calibration setting - do not change
0.30 sec Calibration setting - do not change
3=Y+ Calibration setting - do not change
10% Calibration setting - do not change
See Section 7 for calibration of CE Overload System
-100% Calibration setting - do not change
110% Calibration setting - do not change
Time that the enable bar can be held without operation
10.0 sec
before timeout
0.0 sec Delay before function after enable bar is actuated
0.2 sec Function enabled after operator release
0.0 sec Delay before throttle enabled (not used)
10.0 sec Starter over-crank feature; time starter is off (not used)
